Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ONPOW
-
Model Number:
-
ONPOW61
-
IP level:
-
ip65
-
Dia.:
-
16mm/19mm/22mm
-
Head shape:
-
Flat
-
Contact Configuration:
-
1NO1NC
-
Operation Type:
-
Momentary/Latching
-
Illuminated type:
-
Ring illuminated
-
LED color:
-
Can be customized
-
Housing Material:
-
Stainless steel
-
Operation pressure:
-
About 2.5N
-
Certifications:
-
CE, RoHS
-
Certification:
-
CE,ROHS,REACH,ROHS,UL
Quick Details
-
Protection Level:
-
IP65/IP67
-
Max. Current:
-
5A
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
ONPOW
-
Model Number:
-
ONPOW61
-
IP level:
-
ip65
-
Dia.:
-
16mm/19mm/22mm
-
Head shape:
-
Flat
-
Contact Configuration:
-
1NO1NC
-
Operation Type:
-
Momentary/Latching
-
Illuminated type:
-
Ring illuminated
-
LED color:
-
Can be customized
-
Housing Material:
-
Stainless steel
-
Operation pressure:
-
About 2.5N
-
Certifications:
-
CE, RoHS
-
Certification:
-
CE,ROHS,REACH,ROHS,UL
| brand | ONPOW |
| mounting hole dia. | 16mm/19mm/22mm/25mm |
| part number | ONPOW61 |
| switch ratings | Ui:250V;Ith:5A |
| contact | 1NO1NC |
| operation type | momentary/latching |
| terminal type | pin terminal |
| housing material | stainless steel |
| button material | stainless steel |
| illuminated type | ring illuminated |
| LED color | red,green,yellow,blue,white,RGB |
| LED voltage | 6V,12V,24V,110V,220V other voltage could be customized |
| electronical life | Momentary button≥1000K cycles,latching button≥500K cycles |
| Protection level | IP40/IP65 |
Pls contact me to confirm the product details before ordering.
For large qty,we could give you more discount!
