Quick Details
-
Pitch:
-
3.5/3.81mm
-
Clamp:
-
Phosphor bronze,Ni plated
-
Shrapnel:
-
Stainless steel
-
Housing:
-
PA66, UL94V-0
-
Standard:
-
UL/IEC
-
Rated voltage:
-
300V/250V
-
Rated current:
-
8A/7A
-
Wire range:
-
28-16AWG/1.5mm²
-
Contact resistance:
-
20mΩ
-
Insulation resistance:
-
500MΩ/DC500V
Quick Details
-
Place of Origin:
-
zhejiang
-
Brand Name:
-
jialian
-
Model Number:
-
JL15EDGKD
-
Pitch:
-
3.5/3.81mm
-
Clamp:
-
Phosphor bronze,Ni plated
-
Shrapnel:
-
Stainless steel
-
Housing:
-
PA66, UL94V-0
-
Standard:
-
UL/IEC
-
Rated voltage:
-
300V/250V
-
Rated current:
-
8A/7A
-
Wire range:
-
28-16AWG/1.5mm²
-
Contact resistance:
-
20mΩ
-
Insulation resistance:
-
500MΩ/DC500V
Product Description
Specification
|
Pitch
|
3.5/3.81mm
|
|
Clamp
|
Phosphor bronze,Ni plated
|
|
Shrapnel
|
Stainless steel
|
|
Housing
|
PA66, UL94V-0
|
|
Standard
|
UL/IEC
|
|
Rated voltage
|
300W/250V
|
|
Rated current
|
8A/7A
|
|
Wire range
|
28-16AWG/1.5mm²
|
|
Contact resistance
|
20mΩ
|
|
Insulation resistance
|
500MΩ/DC500V
|
|
Withstanding voltage
|
AC2000V/1Min
|
|
Temp.range
|
-40℃~+105℃
|
|
Strip length
|
6-7mm
|
