Quick Details
-
Warranty:
-
30 year
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM550M10-72HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1138*35mm
-
Solar cell:
-
188*188mm
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Home System
-
Power:
-
550w
-
Weight:
-
32KGS
-
Glass:
-
3.2mm (0.13inches) AR Coating Tempered Glass
-
Efficiency:
-
21.3%
-
Back Sheet:
-
TPT 0.3mm
-
Dimension:
-
2279*1134*35mm
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell
-
Panel Efficiency:
-
21.3%
-
Warranty:
-
30 year
-
Brand Name:
-
Bluesun
-
Model Number:
-
BSM550M10-72HPH
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
2094*1138*35mm
-
Solar cell:
-
188*188mm
-
Frame:
-
Anodized Aluminium Alloy
-
Application:
-
Solar Home System
-
Power:
-
550w
-
Weight:
-
32KGS
-
Glass:
-
3.2mm (0.13inches) AR Coating Tempered Glass
-
Efficiency:
-
21.3%
-
Back Sheet:
-
TPT 0.3mm
-
Dimension:
-
2279*1134*35mm
Click on the image to learn more
Bluesun Project
Advantages of Bluesun
Technical Service Team
Products Description
Bifacial PERC Solar Cell
For a bifacial PERC cell, the Al back surface field is replaced by Al grid, hence render the majority of rear side transparent which enable the cell to absorb light and generate electricity from both sides.
For a bifacial PERC cell, the Al back surface field is replaced by Al grid, hence render the majority of rear side transparent which enable the cell to absorb light and generate electricity from both sides.
|
ELECTRICAL PARAMETERS at STC
|
|
|
|
|
|
|||||
|
Module Type
|
BSM530M10-72HBD
|
BSM535M10-72HBD
|
BSM540M10-72HBD
|
BSM545M10-72HBD
|
BSM550M10-72HBD
|
|||||
|
Maximum Power (Pmax/W)
|
530
|
535
|
540
|
545
|
550
|
|||||
|
Operating Voltage (Vmpp/V)
|
41.32
|
41.48
|
41.64
|
41.8
|
41.96
|
|||||
|
Operating Current (Impp/A)
|
12.83
|
12.9
|
12.97
|
13.04
|
13.11
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
49.32
|
49.46
|
49.6
|
49.76
|
49.92
|
|||||
|
Short-Circuit Current (Isc/A)
|
13.72
|
13.79
|
13.86
|
13.93
|
14
|
|||||
|
Module Efficiency (%)
|
20.5
|
20.6
|
20.8
|
21
|
21.2
|
|||||
|
Performance at NMOT
|
|
|
|
|
|
|||||
|
Maximum Power (Pmax/W)
|
395
|
398
|
402
|
406
|
410
|
|||||
|
Operating Voltage (Vmpp/V)
|
38.6
|
38.7
|
38.8
|
39
|
39.1
|
|||||
|
Operating Current (Impp/A)
|
10.24
|
10.3
|
10.36
|
10.41
|
10.47
|
|||||
|
Open-Circuit Voltage (Voc/V)
|
46.4
|
46.5
|
46.7
|
46.8
|
47.0
|
|||||
|
Short-Circuit Current (Isc/A)
|
11.06
|
11.12
|
11.17
|
11.23
|
11.28
|
|||||
|
|
|
|
|
|
||||||
Bluesun Factory
Bluesun Solar---is one of the solar power solution leading companies in China. Specializing in research and development of solar panel, lithium battery and BMS. Bluesun product has exported to more than 185 countries and regions since 2022. We devote ourselves to provide excellent solar solution.
