Quick Details
-
Model Number:
-
CC-1
-
Disc:
-
Ceramic Disc Catridge
-
material:
-
brass
-
Working times:
-
300000-500000 Times
-
color:
-
brass,chrome plated
-
size:
-
1/2 " 3/8 " 3/4"
-
weight:
-
26-120g
-
Flatness:
-
0.6μM
-
Roughness:
-
Ra0.25μM
-
Hardness:
-
1100Hv5
-
Certificate:
-
ISO90001 CE
Quick Details
-
Material:
-
Brass
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Jintong
-
Model Number:
-
CC-1
-
Disc:
-
Ceramic Disc Catridge
-
material:
-
brass
-
Working times:
-
300000-500000 Times
-
color:
-
brass,chrome plated
-
size:
-
1/2 " 3/8 " 3/4"
-
weight:
-
26-120g
-
Flatness:
-
0.6μM
-
Roughness:
-
Ra0.25μM
-
Hardness:
-
1100Hv5
-
Certificate:
-
ISO90001 CE
|
Technical data: |
|
Max.temperature:90°C |
|
Max.turn angle :90° |
|
Lever tongue test:0.3-0.4n.m(static pressure is zero ) |
|
Noise test ; Max20 db at 3 bar(with noise reducer ) |
|
Working pressure :Max 1.2MPa |
|
Lever break tonque:15Nm |
|
Sealing test :0.8Mpa (fully tested one by one ) |
|
Max pressure :water static pressure max3Mpa |
|
Life test:According to the En 817,Gb18145-2011 standard>300,000cycles, |
|
According to the ASME A112,18.1-2011 standard>500,000cycles |
|
Ceramic disc;Hardness>1150HVS |
|
Flatness : 0.6um |
|
Roughness:Ra0.25um |
|
Porosity:60-80% |
A.Advantages:
1. We are a factory specialized in providing brass products for many years ,such as Brass fittings,Brass Cartridge ,Brass Bar,Water tap ,Floor Drainer which used in sanitary equipment.
2 . Low MOQ (1pc is even acceptable in some special conditions) ;
3 . samples are always free, Delivery time 1-3 days. If customtomized samples, Cost is according to your drawing. 7 days for pre-production sample.
4 . Payment Terms: 30 -50%T/T in advance, 70-50% balance before delivery; PayPal or Western Union accept ed .
5 . Customized size and OEM available ;
6 . Manufacturer in Ningbo, convenience in transportation.
B. quality guaranteed:
100% inspection before shipment.
