Quick Details
-
Brand Name:
-
AE
-
Model Number:
-
AE-100
-
Material:
-
6061-T6 Aluminum Alloy Frame+ Galvanized Square Tube keel
-
Base board:
-
15mm High pressure laminate, plywood, Customer-supplied Materials
-
Finishing option:
-
Acoustical Fabric, Veneer, and Even Customer-supplied Materials
-
Function:
-
Sliding, Operable, Fold-away, Suspending, Dividing, Soundproofing
-
Design:
-
Patented Safety Devices
-
Thickness:
-
105mm
-
Height:
-
Max20 meter
-
Carrier over load:
-
Max 1860kg
-
Sound Insulation:
-
Max 56dB
Quick Details
-
Application:
-
Hotel, Office Building, Hospital, School, Mall, Sports Venues, Hall, Banquet hall, meeting room, office room, exhibition hall, laboratory, commercial space
-
Design Style:
-
Contemporary
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
AE
-
Model Number:
-
AE-100
-
Material:
-
6061-T6 Aluminum Alloy Frame+ Galvanized Square Tube keel
-
Base board:
-
15mm High pressure laminate, plywood, Customer-supplied Materials
-
Finishing option:
-
Acoustical Fabric, Veneer, and Even Customer-supplied Materials
-
Function:
-
Sliding, Operable, Fold-away, Suspending, Dividing, Soundproofing
-
Design:
-
Patented Safety Devices
-
Thickness:
-
105mm
-
Height:
-
Max20 meter
-
Carrier over load:
-
Max 1860kg
-
Sound Insulation:
-
Max 56dB
Product Description
| GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS | ||||||
| Dimensions in mm* | Design | |||||
| Series | Element thickness | Element width* (min./max.) | Clear height* (min./max.) | Framed construction | Panel fixing |
Element interconnection/design of
the vertical profiles |
| AE65 | 68 | 600/1,250 | 2,000/4,500 | Aluminium-steel | Freely oscillating |
Aluminium profile
with magnetic strip and sealing lips |
| AE85 | 89 | 600/1,250 | 2,000/5,500 | Aluminium-steel | Freely oscillating |
Aluminium profile
with magnetic strip and sealing lips |
| AE100 | 105 | 600/1,250 | 2,000/18,000 | Aluminium-steel | Freely oscillating |
Aluminium profile
with magnetic strip and sealing lips |
|
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56 Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m * Larger widths possible on application. Provisional details regarding the element heights/element widths indicated can only be confirmed following consultation with the Design Department. ** Depending on the sound insulation/weight |
||||||
