high quality floor heating pipe underfloor pex pert hot water floor heat pipe tube for home heating floor with cheap price

high quality floor heating pipe underfloor pex pert hot water floor heat pipe tube for home heating floor with cheap price

FOB Reference Price: Get Latest Price

≥5000 Meters

US $0.5

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Application:: Bathroom

Design Style:: Modern

Place of Origin:: Anhui, China

Brand Name:: Huanrui

Model Number:: HR-HC-ZWJ-006

Product Name:: Heating cable 220v under floor heat system heating floor kit

Certification:: CE/EAC/TUV

Cold lead:: 2.5m length

Size:: 0.5X1m-0.5x40m

Resistance tolerance:: +10%/-5%

Power output:: 12W/m, 18W/m

Rated Voltage:: 3.6mm

Insulation optional:: TPEE for T-cable(T), XLPE for T-cable(X)

Cable construction:: Twin conductor

Connector:: Out splice

Quick Details

Warranty:: More than 5 years

After-sale Service:: Online technical support, Other

Project Solution Capability:: total solution for projects, Others

Application:: Bathroom

Design Style:: Modern

Place of Origin:: Anhui, China

Brand Name:: Huanrui

Model Number:: HR-HC-ZWJ-006

Product Name:: Heating cable 220v under floor heat system heating floor kit

Certification:: CE/EAC/TUV

Cold lead:: 2.5m length

Size:: 0.5X1m-0.5x40m

Resistance tolerance:: +10%/-5%

Power output:: 12W/m, 18W/m

Rated Voltage:: 3.6mm

Insulation optional:: TPEE for T-cable(T), XLPE for T-cable(X)

Cable construction:: Twin conductor

Connector:: Out splice

Details Images

Name	Heating cable 220v under floor heat system heating floor kit
Sample	Free samples are available
MOQ	5000 meters
OEM and ODM	Available
OEM service	Cable color, cable printing, color boxs. Any other requirements, please contact us.
Cable length	From 7.5 m to 250 m.
Voltage	110V, 120V, 220V, 230V, 240V
Warranty	25 years limited warranty
Delivery time	Usually within 20 days, large orders and OEM orders should be negotiated.

We choose the top quality raw material for all underfloor heating cables, which are environmental protection and energy saving, for example the high quality fluoropolymer insulation, high-intensive outer jacket, export the cable heating conductor terminals, for the heating cable and cold lead coupling/connection, we can provide two kind of manufacturing processes, one is use heat shrinkable tube, the other one is machine injection mold.

Product Paramenters

Part Number	Rated Voltage/Vac	Length/m	Power Output/W	Resistance/Ω
T-cable12-150	230	12.5	150	352.7
T-cable12-225	230	18.8	225	235.1
T-cable12-300	230	25	300	176.3
T-cable12-375	230	31.3	375	141.1
T-cable12-450	230	37.5	450	117.6
T-cable12-525	230	43.8	525	100.8
T-cable12-600	230	50	600	88.2
T-cable12-675	230	56.3	675	78.4
T-cable12-750	230	62.5	750	70.5
T-cable12-900	230	75	900	58.8
T-cable12-1050	230	87.5	1050	50.4
T-cable12-1200	230	100	1200	44.1
T-cable12-1350	230	112.5	1350	39.2
T-cable12-1500	230	125	1500	35.3
T-cable12-1800	230	150	1800	29.4

Part Number	Rated Voltage/Vac	Length/m	Power Output/W	Resistance/Ω
T-cable18-135	230	7.50	135	391.85
T-cable18-200	230	11.11	200	264.50
T-cable18-270	230	15.00	270	195.93
T-cable18-400	230	22.22	400	132.25
T-cable18-535	230	29.72	535	98.88
T-cable18-600	230	33.33	600	88.17
T-cable18-680	230	37.78	680	77.79
T-cable18-800	230	44.44	800	66.13
T-cable18-935	230	51.94	935	56.58
T-cable18-1100	230	61.11	1100	48.09
T-cable18-1220	230	67.78	1220	43.36
T-cable18-1340	230	74.44	1340	39.48
T-cable18-1500	230	83.33	1500	35.27
T-cable18-1625	230	90.28	1625	32.55
T-cable18-1900	230	105.56	1900	27.84
T-cable18-2135	230	118.61	2135	24.78
T-cable18-2295	230	127.50	2295	23.05
T-cable18-2775	230	154.17	2775	19.06

Part Number	Rated Voltage/Vac	Length/m	Length/ft	Power Output/W	Resistance/Ω
T-cable1-120	120	11.61	38	120	120
T-cable1-180	120	17.42	57	180	80
T-cable1-240	120	23.23	76	240	60
T-cable1-300	120	29.03	95	300	48
T-cable1-360	120	34.84	114	360	40
T-cable1-420	120	40.64	133	420	34.29
T-cable1-480	120	46.45	152	480	30
T-cable1-540	120	52.26	171	540	26.67
T-cable1-600	120	58.06	190	600	24
T-cable1-720	120	69.68	229	720	20
T-cable1-840	120	81.29	267	840	17.14
T-cable1-960	120	92.9	305	960	15
T-cable1-1080	120	104.51	343	1080	13.33
T-cable1-1200	120	116.13	381	1200	12
T-cable1-1440	120	139.35	457	1440	10

Part Number	Rated Voltage/Vac	Length/m	Power Output/W	Resistance/Ω
I-cable20-200	230	10	200	264.5
I-cable20-300	230	15	300	176.3
I-cable20-400	230	20	400	132.3
I-cable20-500	230	25	500	105.8
I-cable20-600	230	30	600	88.2
I-cable20-700	230	35	700	75.6
I-cable20-850	230	42.5	850	62.2
I-cable20-1000	230	50	1000	52.9
I-cable20-1200	230	60	1200	44.1
I-cable20-1400	230	70	1400	37.8
I-cable20-1600	230	80	1600	33.1
I-cable20-1800	230	90	1800	29.4
I-cable20-2000	230	100	2000	26.5
I-cable20-2200	230	110	2200	24
I-cable20-2400	230	120	2400	22
I-cable20-2600	230	130	2600	20.3
I-cable20-2800	230	140	2800	18.9
I-cable20-3100	230	155	3100	17.1
I-cable20-3600	2300	180	3600	14.7
