Quick Details
-
Brand Name:
-
Carspa
-
Model Number:
-
SC1210
-
Work Time (h):
-
24
-
Max PV Power:
-
10
-
Max PV Voltage:
-
22
-
Charge mode:
-
PWM
-
Rated charge current:
-
10a/20a/30a
-
Battery type:
-
Lead Acid/ GEL/ Lithium
-
Working Temperature:
-
-35 ~ +60℃
-
Weight:
-
154g
-
USB output:
-
5V 2.1A
-
Warranty:
-
2 years
-
Display:
-
LCD
-
Max.PV input:
-
55V
-
Power Conversion Efficiency:
-
70%-80%
Quick Details
-
Type:
-
PWM
-
Application:
-
Solar System Controller
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Carspa
-
Model Number:
-
SC1210
-
Work Time (h):
-
24
-
Max PV Power:
-
10
-
Max PV Voltage:
-
22
-
Charge mode:
-
PWM
-
Rated charge current:
-
10a/20a/30a
-
Battery type:
-
Lead Acid/ GEL/ Lithium
-
Working Temperature:
-
-35 ~ +60℃
-
Weight:
-
154g
-
USB output:
-
5V 2.1A
-
Warranty:
-
2 years
-
Display:
-
LCD
-
Max.PV input:
-
55V
-
Power Conversion Efficiency:
-
70%-80%
Technical Parameter:
| Model | 1210 | 1220 | 1230 |
| Sytem Voltage | 12/24v | 12/24v | 12/24v |
| Charge Current | 10A | 20A | 30A |
| Discharge Current | 10A | 20A | 30A |
| Max Solar Input | 50V | 50V | 50V |
| Battery Type |
b01 Sealed
b02 GEL
b03 Flood |
b01 Sealed b02 GEL b03 Flood |
b01 Sealed b02 GEL b03 Flood |
| Equalization | 14.4V | 14.4V 14.2V | 14.2V |
| Battery type |
b04 Iron lithium 4 strands b05 Iron lithium 5 strands b06 lithium ion 3 strands b07 lithium ion 4 strands |
Same as above | Same as above |
| Operating Temperature | -35 to +60 ℃ | -35 to +60 ℃ | -35 to +60℃ |
Attention: b04~b07 Parameters can not be set
