Quick Details
-
Power:
-
86kw
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
ZOOMLION
-
Maximum Digging Height:
-
8415mm
-
Maximum Digging Depth:
-
5495mm
-
Machine Weight:
-
14000 kg
-
Max Digging Radius:
-
8540mm
-
Rated Speed:
-
5.3/3.0km/h
-
Engine:
-
86KW
-
Operating weight:
-
14000kg
-
Standard capacity:
-
0.55m3
-
Traveling speed:
-
5.3/3.0km/h
Quick Details
-
Operating Weight:
-
7TON, 6 ton, 7.5 TON
-
Bucket capacity:
-
0.55
-
Engine Brand:
-
IMPORTED
-
Power:
-
86kw
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
ZOOMLION
-
Maximum Digging Height:
-
8415mm
-
Maximum Digging Depth:
-
5495mm
-
Machine Weight:
-
14000 kg
-
Max Digging Radius:
-
8540mm
-
Rated Speed:
-
5.3/3.0km/h
-
Engine:
-
86KW
-
Operating weight:
-
14000kg
-
Standard capacity:
-
0.55m3
-
Traveling speed:
-
5.3/3.0km/h
ZOOMLION 13 ton 14 ton crawler excavator for construction ZE135E-10
Sales Manager
Jason Fan
Newindu International Ltd.
Skype:
live:415543932
Mobile/ Whatsapp/ Wechat: +86-176 3420 6423
Email: jason (at) newindu.com
Fuel consumption per hour has been further reduced, and work efficiency & fuel efficiency have been greatly enhanced thanks to the tailored load-sensing system. Three work modes can be optimally matched under corresponding applications, thus delivering enhanced work efficiency with saved energy.
| Items | Units | ZE135E-10 | |
| Basic Technical Data | Operating Weight | kg | 7500 |
| Standard Capacity | m³ | 0.55 | |
| Slewing Speed | r/min | 12 | |
| Traveling Speed(high/low) | km/h | 5.3/3.0 | |
| Max. Drawbar Pull | kN | 123 | |
| Digging Force of Bucket | kN | 96 | |
| Digging Force of Stick | kN | 71 | |
|
Engine |
Engine Manufacturer | / | Imported |
| Engine Model | / | QSF3.8 | |
| Rated Power | kW/rpm | 86/2200 | |
| Displacement | L | 3.8 | |
| Emission Standard | / | EU Stage IIIA | |
|
Dimensions |
Length | mm | 8090 |
| Width | mm | 2500 | |
| Height | mm | 2900 | |
| Tail Slewing Radius | mm | 2470 | |
| Track Gauge | mm | 2000 | |
| Length of Track On Ground | mm | 3005 | |
| Operating Range | Max. Digging Radius | mm | 8540 |
| Max. Digging Reach | mm | 8415 | |
| Max. Digging Depth | mm | 5495 | |
| Max. Digging Height | mm | 8690 | |
| Max. Dumping Height | mm | 6055 | |
