Quick Details
-
Warranty:
-
10
-
Brand Name:
-
Times Power
-
Model Number:
-
TP-SP007
-
Place of Origin:
-
Gansu, China
-
Panel Dimensions:
-
1580*710*30MM
-
Product name:
-
Photovoltaic Solar Panels
-
Application:
-
Solar Power System
-
Junction Box:
-
SY-005 rated
-
Solar cell:
-
Monocrystalline silicon solar cells
-
Connector:
-
MC4
-
OEM Order:
-
Acceptable
-
Weight:
-
15kg
-
Front Glass:
-
silicon wafer
-
Open circuit voltage(V):
-
43.2V
-
short circuit current(A):
-
7.02A
-
Certificate:
-
CE/TUV
Quick Details
-
Cell size:
-
166mmx166mm
-
Type:
-
PERC
-
Panel Efficiency:
-
20.5%
-
Warranty:
-
10
-
Brand Name:
-
Times Power
-
Model Number:
-
TP-SP007
-
Place of Origin:
-
Gansu, China
-
Panel Dimensions:
-
1580*710*30MM
-
Product name:
-
Photovoltaic Solar Panels
-
Application:
-
Solar Power System
-
Junction Box:
-
SY-005 rated
-
Solar cell:
-
Monocrystalline silicon solar cells
-
Connector:
-
MC4
-
OEM Order:
-
Acceptable
-
Weight:
-
15kg
-
Front Glass:
-
silicon wafer
-
Open circuit voltage(V):
-
43.2V
-
short circuit current(A):
-
7.02A
-
Certificate:
-
CE/TUV
Product Description
|
Parameter
|
|
|
|
Cell Type
|
Monocrystalline Silicon Solar Cell
|
|
|
Rated power
|
230WP
|
|
|
Product size
|
1580*710*30MM
|
|
|
Module efficiency
|
20.5%
|
|
|
Number of cells
|
72
|
|
|
Power tolerance
|
+/-3%
|
|
|
Open circuit voltage
|
43.2V
|
|
|
Short circuit current
|
7.02A
|
|
|
Maximum power point operating voltage
|
36V
|
|
|
Maximum power point operating current
|
8.33A
|
|
|
Irradiation ratio
|
1000W/M2
|
|
|
Front glass
|
Silicon wafer
|
|
|
Encapsulation material
|
EVA
|
|
|
Rear glass
|
white back
|
|
|
Frame
|
Aluminum frame
|
|
|
Junction Box
|
SY-005 rated
|
|
|
Cable
|
4.0mm² (0.16 inches2), Length: 0.9m (35.4 inches)
|
|
|
Connector
|
MC4
|
|
|
Service life
|
25 years
|
|
|
Shelf life
|
10 years
|
|
