Quick Details
-
Power (kW):
-
18
-
Name:
-
Double Sides Sander
-
Application:
-
Wood furniture processing
-
characteristics:
-
Efficient, automatic
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KAIYUANJINGKE
-
Weight (KG):
-
2600 KG
-
Power (kW):
-
18
-
Name:
-
Double Sides Sander
-
Application:
-
Wood furniture processing
-
characteristics:
-
Efficient, automatic
1.It is suitable for sanding
straight-line special-shaped edges of cabinets, furniture and wooden doors
. On the premise of ensuring that the head and tail of the workpiece are not damaged, the blank and primer sanding of the processing edges of various plates shall be solved.
2.Excellent performance: belt type pressing, spring load, reliable pressing, without damaging the workpiece.
3.The
sanding head can adjust the angle
.
4.The
sanding frame
has
up and down vibration adjustment function
to ensure good heat dissipation and smoothness of the sanded surface.
5.The pressure beam adopts thick belt and spring load, and the pressing plate is stable and reliable without damaging the workpiece.
Standard 400 type
triangular sanding frame
Multifunctional sponge
wheel sanding head
Description: the
sanding head
is
matched with
the
universal standard grinding wheel
in the world; It can install brush sand roller, octagonal sand, grinding wheel and polishing wheel, and implement omni-directional diversified sanding of special-shaped edges; It also has
automatic telescopic function
to protect the workpiece’s head and tail, the
grinding wheel
has
automatic compensation function
.
Features: good universality for the machined surface and strong abrasive matching. It can
sand any special-shaped surface
.
Fine chamfered parts
It has
double-sided automatic tracking function
, which is specially used for arc chamfering of the edge of the workpiece; The motor body can be adjusted by 0-45 °.
Features: it has high machining precision and good stability, and has
excellent effect on small chamfers below R3
.
Imitation milling head parts
It can process milling processes such as workpiece edge forming, chamfering, slotting and trimming; The
angle of the motor body can be adjusted
; Simple operation, simple and convenient tool replacement.
Features:
fixed installation, strong milling force
. 3.7KW, 5.5KW, 7.5KW and 9KW high-speed motors are available.
|
Model
|
MMZ-S2W4
|
|
Workpiece width
|
100-1800mm
|
|
Maximum thickness of workpiece
|
80mm
|
|
Working height
|
850mm
|
|
Feeding speed
|
0~30m/min
|
|
Total power
|
18kw
|
|
Dimension
|
5580×1500×1500mm
|
|
Net weight
|
2600kg
|
FOSHAN KAIYUAN JINGKE MACHINERY CO., LTD. is located in Shunde Lunjiao, the leading city of woodworking machinery manufacturing in China. It is committed to provide customers with the
solutions of blank, painting
and
sanding for the surface
of various workpieces such as
doors, windows, picture frames, cabinets, closets, bathrooms, wood lines
, etc.
It has many senior technical personnel, serving the R & D, production and after-sales departments. Based on years of equipment manufacturing experience, KAIYUAN JINGKE machinery actively absorbs and introduces advanced technology and management mode at home and abroad, and produces a variety of high-quality products with
advanced equipment
and mature technology:
Production line, Wide brush sander, Linear sander, Edge sander, UV Edge painting, Sand blasting machine, Curve sander, Primer sander
and
Automatic auxiliary equipment
, It has been widely used in the industry.
In order to help customers better to improve product quality, increase productivity, and enhance their competitiveness, KAIYUAN JINGKE Machinery has established a comprehensive and effective sales and service network in the country, and committed to provide thorough pre-sale, selling and after-sales service to the new and old customers. The company focus on the implementation of performance management and user feedback, and improve itself in terms of quality service and so on, and do everything possible to meet customer needs to achieve win-win situation.
1. What is your minimum quantity order?
A: One set.
2. Are you trading company or manufacturer ?
A: We are a manufacturer in China. We have own factory in Foshan.
3. What is your term of payment?
A: 30-50% TT for deposit, balance before the shipping.
4. Can you accept the Alibaba trade insurance order?
A: Yes, of course. We are happy to use Trade insurance to confirm the order on Alibaba.
5. Can you supply the sample?
A: We do not provide machine samples, but you can send the product samples, and we will try the machine for you; Or, we can contact the buyer near you. If there is a similar machine, we can let you go to check and try it out.
6. When you can delivery the goods?
A: Within 30 working days after we received your deposit.
7. Is this installation easy?
A: Yes , our products are easy to install and don't need to be welded and processed again.
8. Can you customized it for us?
A: Our products are usually customized according to customers' products and requirements
If you are interested, please contact us without hesitate. Then we can get touch with you can follow up your project. Thanks
