Quick Details
-
Brand Name:
-
Hosecom
-
Model Number:
-
FR-7N3208P
-
Place of Origin:
-
Guangdong, China
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
20G
-
Brand Name:
-
Hosecom
-
Model Number:
-
FR-7N3208P
-
Place of Origin:
-
Guangdong, China
|
Ports
|
|
8x10/100/1000Base-TX Port(RJ45)
2x1000Base-X(SFP/1x9) |
|
|
|||
|
Port Mode(Tx)
|
|
Auto Negotiation
Full/Half Duplex Mode Auto MDI/MDI-X Connection |
|
|
|||
|
Standards
|
|
IEEE 802.3 for 10BaseT
IEEE 802.3u for Fast Ethernet IEEE 802.3ab Gigabit Ethernet IEEE 802.3x for flow control and back pressure IEEE802.3az for Energy Efficient Ethernet(EEE) |
|
|
|||
|
Packet Buffer Size
|
|
2M
|
|
|
|||
|
Maximum Packet Length
|
|
9K
|
|
|
|||
|
MAC Address Table
|
|
4K
|
|
|
|||
|
Transmission Mode
|
|
Store and Forward (full/half duplex mode)
|
|
|
|||
|
Exchange Property
|
|
Delay time: < 7μs
Backplane bandwidth: 20G |
|
|
|||
|
PoE Ports
|
|
Port 1 to 8 IEEE802.3af/at @PoE+
|
|
|
|||
|
Power Supply Pin
|
|
Default: 1/2(+), 3/6(-)
|
|
|
|||
|
Total PWR /Input Voltage
|
|
240W(DC48-56V) (Model dependent)
|
|
|
|||
|
Protection
|
|
Overload Current Protection, Reverse Polarity Protection
|
|
|
|||
|
Warranty
|
|
5 Years
|
|
|
|||
