Quick Details
-
Color:
-
Full color
-
Panel Size:
-
customize
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P50
-
Pixel Pitch:
-
50mm
-
Brightness:
-
1500-3000cd/㎡
-
pixel density:
-
10000 pixels/㎡
-
Contrast Ratio:
-
customize
-
Color Depth:
-
all
-
Lifespan (hours):
-
≥100,000 hours.
-
IP Rating:
-
IP67
-
HS Code:
-
8528591090
-
Resolution:
-
4K or customize
-
View Angle（H/V）:
-
H: ≥160°; V ≥120°
-
Pixel composition:
-
SMD2727
-
Module Size:
-
500X5000mm
-
Maximum white balance brightness:
-
1500-3500cd/㎡
-
Gray level:
-
Red, green, and blue ≥ 256 levels, up to 65536 levels
-
Display color:
-
≥16.7M species, up to 281 trillion species
-
Out of control points:
-
≤1/10000
-
Device driver:
-
Static Scan
-
Refresh rate:
-
1920Hz
-
Operating Voltage:
-
AC 110~220V±15%,50Hz±2 Hz
-
Installation Method:
-
Building Led Mesh Media Facade decoration, advertisement sign
Quick Details
-
Application:
-
Indoor, Outdoor, Semi-outdoor
-
Type:
-
LED
-
Brand Name:
-
Ryham
-
Color:
-
Full color
-
Panel Size:
-
customize
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
P50
-
Pixel Pitch:
-
50mm
-
Brightness:
-
1500-3000cd/㎡
-
pixel density:
-
10000 pixels/㎡
-
Contrast Ratio:
-
customize
-
Color Depth:
-
all
-
Lifespan (hours):
-
≥100,000 hours.
-
IP Rating:
-
IP67
-
HS Code:
-
8528591090
-
Resolution:
-
4K or customize
-
View Angle（H/V）:
-
H: ≥160°; V ≥120°
-
Pixel composition:
-
SMD2727
-
Module Size:
-
500X5000mm
-
Maximum white balance brightness:
-
1500-3500cd/㎡
-
Gray level:
-
Red, green, and blue ≥ 256 levels, up to 65536 levels
-
Display color:
-
≥16.7M species, up to 281 trillion species
-
Out of control points:
-
≤1/10000
-
Device driver:
-
Static Scan
-
Refresh rate:
-
1920Hz
-
Operating Voltage:
-
AC 110~220V±15%,50Hz±2 Hz
-
Installation Method:
-
Building Led Mesh Media Facade decoration, advertisement sign
Product Description
| LED Mesh Screen Specifications | ||||
| ITEM | P31.25 | P50 | P62.5 | P100 |
| Product Shell Color | Black/ Transparent | Black/ Transparent | Black/ Transparent | Black/ Transparent |
| Pixel Pitch | 31.25mm | 50mm | 62.5mm | 100mm |
| LED type | RGB 3in1 SMD 2727 | RGB 3in1 SMD 2727 | RGB 3in1 SMD 2727 | RGB 3in1 SMD 2727 |
| LED Pixel composition | 2 LEDs in 1 Pixel | 2 LEDs in 1 Pixel | 2 LEDs in 1 Pixel | 2 LEDs in 1 Pixel |
| Pixel Density | 1024dot/m2 | 400dot/m2 | 256dot/m2 | 100dot/m2 |
| Unit panel size | 500X5000mm Up to 15m | 500X5000mm Up to 15m | 500X5000mm Up to 15m | 500X5000mm Up to 15m |
| Weight | 6kg/m2 | 3Kgs/m2 | 3Kgs/m2 | 3Kgs/m2 |
| Waterproof rate | IP67 | IP67 | IP67 | IP67 |
| Brightness | 3000nits | 2000nits | 1200nits | 800nits |
| View Distance | ≥15m | ≥25m | ≥30m | ≥50m |
| Viewing Angle (H/V) | 160°/120° | 160°/120° | 160°/120° | 160°/120° |
| Gray Scale | 14 bit | 14 bit | 14 bit | 14 bit |
| Max.Power Consumption | 500W/SQM | 160W/SQM | 120W/SQM | 50W/SQM |
| Ave .Power Consumption | 150W/SQM | 60W/SQM | 40W/SQM | 15W/SQM |
| Refresh rate | 1280HZ | 1280HZ | 1280HZ | 1280HZ |
| Applied environment | OUTDOOR | OUTDOOR | OUTDOOR | OUTDOOR |
| Controller | Synchronous display with control PC by DVI/ Or Asynchronous Control | Synchronous display with control PC by DVI/ Or Asynchronous Control | Synchronous display with control PC by DVI/ Or Asynchronous Control | Synchronous display with control PC by DVI/ Or Asynchronous Control |
| Support Input | Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI | Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI | Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI | Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI |
| Power input | AC110~240 50/60HZ | AC110~240 50/60HZ | AC110~240 50/60HZ | AC110~240 50/60HZ |
| Environment | temperature -40℃~+60℃,humidity 10~90% RH | temperature -40℃~+60℃,humidity 10~90% RH | temperature -40℃~+60℃,humidity 10~90% RH | temperature -40℃~+60℃,humidity 10~90% RH |
| Operating Life | 100,000hours | 100,000hours | 100,000hours | 100,000hours |
