Quick Details
-
Size:
-
1460(L)*1400(W)*1635mm(H)
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Tong Yang
-
Power:
-
7.5KW
-
Name:
-
washing machines turkey
-
Capacity:
-
15kg~100Kg
-
Maintenance:
-
Convenient
-
Heat:
-
Steam, electric, hot water
-
Pressure:
-
0.4-0.6Mpa
-
Used for:
-
Launry washing
-
Operation:
-
Easy
-
Controller:
-
Automatic
-
Service:
-
Good
Quick Details
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Video technical support, Free spare parts
-
Weight:
-
1250KG
-
Size:
-
1460(L)*1400(W)*1635mm(H)
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Tong Yang
-
Power:
-
7.5KW
-
Name:
-
washing machines turkey
-
Capacity:
-
15kg~100Kg
-
Maintenance:
-
Convenient
-
Heat:
-
Steam, electric, hot water
-
Pressure:
-
0.4-0.6Mpa
-
Used for:
-
Launry washing
-
Operation:
-
Easy
-
Controller:
-
Automatic
-
Service:
-
Good
washing machines turkey
Specification:
| Model | XTQ-15H | XTQ-20H | XTQ-30H | XTQ-50H | XTQ-70H | XTQ-100H | |||||
| Rated capacity (kg) | 10-15kg | 15-20kg | 20-30kg | 35-50kg | 50-70kg | 70-100kg | |||||
| Motor power (kw) | 2.2kw | 2.2kw | 4.0kw | 5.5kw | 7.5kw | 7.5kw | |||||
| Electrical power(kw) | 12kw | 15kw | 24kw | 36kw | - | - | |||||
| Roller dimension (mm) | 650mm | 673mm | 902mm | 1060mm | 1200mm | 1200mm | |||||
| Roller deep (mm) | 450mm | 550mm | 500mm | 605mm | 626mm | 815mm | |||||
| Roller volume | 149Lit | 195Lit | 320Lit | 504Lit | 708Lit | 920Lit | |||||
| Average speed (r/min) | 90r/min | 90r/min | 72r/min | 75r/min | 70r/min | 65r/min | |||||
| Washing speed (r/min) | 50r/min | 45r/min | 36r/min | 35r/min | 33r/min | 31r/min | |||||
| Middle dewater speed (r/min) | 450r/min | 400r/min | 420r/min | 380r/min | 350r/min | 310r/min | |||||
|
High dewater speed
(r/min) |
890r/min | 820r/min | 780r/min | 760r/min | 680r/min | 680r/min | |||||
| Steam pipe | 3/4" | 3/4' ' | 1" | 1" | 1" | 1" | |||||
| Cold water pipe | 3/4" | 3/4' ' | 3/2" | 3/2" | 3/2" | 3/2" | |||||
| Hot water pipe | 3/4" | 3/4' ' | 3/2" | 3/2" | 3/2" | 3/2" | |||||
| Drain valve | φ 70mm | φ 70mm | φ 140mm | φ 140mm | φ 140mm | φ 140mm | |||||
| Power supply | Standard: 380+N-3PH-50HZ | ||||||||||
|
Overall size
(length*width*height) mm |
1010*1110
*1510 |
1100*1020
*1500 |
1410*1430
*1760 |
1650*1750
*1900 |
1850*1800
*2300 |
1850*2000
*2300 |
|||||
|
Weight (kg)
weight |
950kg | 980kg | 1900kg | 2600kg | 2800kg | 3130kg | |||||
Main features:
1. laundry washer extractor Fully automatic, microcomputer-controlled.
2. Industrial washer extractor has high quality 304'' stainless steel, good appearance, long life.
3. Microprocessor,freely programmable,5 standard programmers, 25 possible programmers.
4. Full suspension shock sructure, suspension, combination of shock absorbers and springs for maximum absorption, need no excessive foundations.
5. Imported bearing, precise and durable.
6. Fixed support for long-distance transportation, avoid shaking damage during transit.
7. laundry washer extractor has high quality inverter system, easily realize washing and dehydration frequency steep adjusting.
8, Built-out bearing lubrication, simple operation, convenient maintenance.
9, Safety door interlock system.
10, Multiple sealing system, oil sealing , water sealing, stainless steel sealing.
11. With CE and ISO9001 certificates.
