Quick Details
Quick Details
-
Place of Origin:
-
ZHE
-
Brand Name:
-
XT
-
Model Number:
-
UK5-HESI
2.:To the terminal block with many sections fit out the unit accessory like header,separating plate and so on
3.Electric potential allocated can through accessing to the center of terminal block fixed type or interesting to the edgegrip of the terminal blocks to make that true
4.Compared with the same common the grounding blocks and N type terminal blocks ,we adopted marking system can realize ZB ...combination of digital unified label
General
|
Number of levels |
1 |
|
Number of connections |
2 |
|
Nominal cross section |
10mm² |
|
C olor |
|
|
Insulating material |
PA |
|
Flammability rating according to UL 94 |
V0 |
|
Rated surge voltage |
6Kv |
|
Degree of pollution |
3 |
|
Connection in acc. with standard |
GB30847/IEC 60947-7-1 |
|
R ated operational current |
57A |
|
R ated operational voltage |
400V |
|
R ated current max. |
57A |
|
R ated voltage max. |
400V |
|
Temperature index |
130RTI/120TI |
