Quick Details
-
Warranty:
-
10YEARS
-
Brand Name:
-
Green System
-
Model Number:
-
KXSF N36-80, KXSF N36-80
-
Place of Origin:
-
Jiangxi, China
-
Panel Dimensions:
-
1709mm*348mm
-
Solar Panels Connectors:
-
MC4(waterproof)
-
Solar Panels Frame:
-
Corrosion-resistant aluminum
-
Power Tolerance:
-
0-+5W
-
OEM/ODM:
-
Welcome
-
Wind Load:
-
2400Pa
-
Snow Load:
-
5400Pa
-
Color's Selection:
-
white
-
Solar Panels Style:
-
Luxury
-
Solar Panels System:
-
Pls inquiry to plan for you
-
Certificate:
-
CE,ACC,PSE
Quick Details
-
Cell size:
-
1709mm*348mm*20mm
-
Type:
-
PERC, N-TYPE, TOPCON, Flexible
-
Panel Efficiency:
-
16.2%
-
Warranty:
-
10YEARS
-
Brand Name:
-
Green System
-
Model Number:
-
KXSF N36-80, KXSF N36-80
-
Place of Origin:
-
Jiangxi, China
-
Panel Dimensions:
-
1709mm*348mm
-
Solar Panels Connectors:
-
MC4(waterproof)
-
Solar Panels Frame:
-
Corrosion-resistant aluminum
-
Power Tolerance:
-
0-+5W
-
OEM/ODM:
-
Welcome
-
Wind Load:
-
2400Pa
-
Snow Load:
-
5400Pa
-
Color's Selection:
-
white
-
Solar Panels Style:
-
Luxury
-
Solar Panels System:
-
Pls inquiry to plan for you
-
Certificate:
-
CE,ACC,PSE
Product Details
|
Models
|
KXSF N36-75
|
KXSF N36-80
|
CUSTOMIZE
|
|||
|
Nominal Power (PMPP)
|
75W
|
80W
|
customize
|
|||
|
Aperture Efficiency (η)
|
15.20%
|
15.20%
|
customize
|
|||
|
Maximum Power Voltage (VMPP)
|
18.3V
|
18.8V
|
customize
|
|||
|
Maximum Power Current (IMPP)
|
4.09A
|
4.26A
|
customize
|
|||
|
Open Circuit Voltage (VOC)
|
23.3V
|
23.8V
|
customize
|
|||
|
Short Circuit Current (ISC)
|
4.7A
|
4.74A
|
customize
|
|||
|
Maximum Series Fuse Rating
|
10A
|
|
customize
|
|||
|
Standard Test Conditions :1000W/m2,25℃ Cell temperature,AM 1.5 spectrum
|
|
|
customize
|
|||
|
THERMAL CHARACTERISTICS
|
|
|
|
|||
|
NOCT
|
[℃ ]
|
48
|
customize
|
|||
|
Temperature Coefficient Of PMPP
|
[%/℃]
|
-0.38
|
customize
|
|||
|
Temperature Coefficient Of VOC
|
[%/℃]
|
-0.28
|
customize
|
|||
|
Temperature Coefficient Of ISC
|
[%/℃]
|
0.008
|
customize
|
|||
|
Cell Temperature Opera Ting Range
|
[℃ ]
|
-40~85
|
customize
|
|||
|
PHYSICAL AND MECHANICAL SPECIFICATIONS
|
|
|
|
|||
|
Length
|
mm
|
1709
|
customize
|
|||
|
Width
|
mm
|
348
|
customize
|
|||
|
Thickness, Maximum at J-Box*
|
mm
|
20
|
customize
|
|||
|
Weight(Module without adhesive)
|
Kg
|
1.2
|
customize
|
|||
|
Weight(Module with adhesive)
|
Kg
|
1.6
|
customize
|
|||
|
Weight/Area (Modulewithout adhesive)
|
kg/m2
|
2.0
|
customize
|
|||
|
Weight/Area(Module with adhesive)
|
kg/m2
|
2.7
|
customize
|
|||
|
Cell Type
|
CIGS
|
|
customize
|
|||
Details Images
It can be installed with mounting glue, suitable for long-term installation.
Installation Scheme 2
With mounting holes, convenient to install in any place.
It adopts the back pasting method, does not need to install the bracket, and is light in weight, and can be pasted anywhere.
*
Quality diode ensures module running safety.
* Waterproof grade IP68.
* Heat dissipation,long service life.
* Waterproof grade IP68.
* Heat dissipation,long service life.
MC4 interface is adopted for convenient connection and waterproof function.
Applications
Marketing Campaign
About Us
Jiangxi Green System is located in Asia's lithium battery industry zone -Yichun City.Jiangxi Province. We committed to providing one-stop photovoltaic solution for global companies, investors, traders, installations and users. Our main product collections include solar panels、inverters、batteries、mounting supports and charge controllers.
