- Product Details
- {{item.text}}
Quick Details
-
Type:
-
HVAC/hot water system
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Mango Energy
-
Model Number:
-
#MGWT-1502LC
-
Function:
-
Hot Water *House Heating*Space Chilling
-
Water volum:
-
150L*2
-
Inner tank material:
-
SUS304/2B (1.5mm)
-
Exchanger coil:
-
2*25M built-in
-
Size (mm):
-
R700*1578
-
N.W./G.W.:
-
94/96 kg
-
Optional:
-
1.5kw*2
Quick Details
-
Warranty:
-
2 years
-
Application:
-
Hotel, Garage, Commercial, Household
-
Power Source:
-
Electric
-
Type:
-
HVAC/hot water system
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Mango Energy
-
Model Number:
-
#MGWT-1502LC
-
Function:
-
Hot Water *House Heating*Space Chilling
-
Water volum:
-
150L*2
-
Inner tank material:
-
SUS304/2B (1.5mm)
-
Exchanger coil:
-
2*25M built-in
-
Size (mm):
-
R700*1578
-
N.W./G.W.:
-
94/96 kg
-
Optional:
-
1.5kw*2
Product Description
2 in 1 SUS304 Hot Water Tank Boiler System Heat Exchanger Coils 150L+150L Sanitary Hot Water Storage Room Heating Buffer Tank
1. Two tanks built-in one buffer in house heating system and one for hot water system;
2. Installation room saving, 2 funtion's tanks taking one room only;
3. Each heat exchanger coil built-in, threaded achieving water system separation and heat exchanging at the same time, rapidly increase heat exchanging rate, highly efficient energy saving;
4. Electric heater built-in is optional for each tank to complete auxiliary heating.
5. High-density AVIATION grade Polyurethane heat preservation, 2℃ lost every 10 hour at most.
6. SUS 304 tank liner with 8A class welding, contant and reliable for serving life over 5 years, without any leakage.
7. TRANQUIL FLOW TECHNOLOGY, the adoption of a diffuser pipe on cold water inlet ensures stable water temperatures in cylinder.
With tranquil flow tech: Cold water flows into the tank gently and does not mix with hot water instantly.
Without tranquil flow technology: Cold water flows into the tank rapidly and cause turbulence and mixing in the cylinder which blends water tem perature downwards.
8. Max water temperature can reach 100℃.
Product Features
Specification
|
item
|
#MGWT-1502LC
|
|
Warranty
|
2 Years
|
|
Application
|
Hotel, Commercial, Household
|
|
Power Source
|
Solar
|
|
N.W./G.W.
|
90/94 kg
|
|
Liner
|
SUS304
|
|
Type
|
HAVC & hot water system
|
|
Installation
|
Freestanding
|
|
Storage / Tankless
|
Storage
|
|
Housing Material
|
Galvanized steel
|
|
Use
|
Bathroom
|
|
Place of Origin
|
China
|
|
Tank size
|
R700*1578
|
|
Brand Name
|
Mango Energy
|
|
Function
|
Hot Water *Space Heating*Space Cooling
|
|
Water volum
|
150L+150L
|
Details Images
Heated water flow in to 200L SUS304 Liner 25M Heat Exchanger Coil Built-in Domestic Hot Water Storage Tank
All series water heater with different kw capacity to supply hot water constantly.
Exchanger coils in 200L SUS304 Liner 25M Heat Exchanger Coil Built-in Domestic Hot Water Storage Tank
Separates water systems and achieve heat exchanging or cold translation.
Heated water flow in to 200L SUS304 Liner 25M C orrugated Pipe Heat Exchanger Coil Built-in Domestic Hot Water Storage Tank
Rapidly increase heat exchang area, improve Coefficient of Heat Exchange.
Heated water flow in to 200L SUS304 Liner 25M Smooth Heat Exchanger Coil Built-in Domestic Hot Water Storage Tank
Decrease water pressure and resistance.
Product Application
2 in 1 SUS304 Hot Water Tank Boiler System Heat Exchanger Coils 150L+150L Sanitary Hot Water Storage Room Heating Buffer Tank
The most inportant
transportation hub
in water system.
Packing & Delivery
2 in 1 SUS304 Hot Water Tank Boiler System Heat Exchanger Coils 150L+150L Sanitary Hot Water Storage Room Heating Buffer Tank
Carton box with foam and polywood.
2 in 1 SUS304 Hot Water Tank Boiler System Heat Exchanger Coils 150L+150L Sanitary Hot Water Storage Room Heating Buffer Tank
