Quick Details
-
Model Number:
-
MTS-203,XT-11B,XT-23A
-
Max. Current:
-
15A
-
Mechanical Life:
-
500,0000 times above
-
Material:
-
Thermoplastic crust
-
Type:
-
Hand reset
Quick Details
-
Max. Voltage:
-
250VAC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XURUI
-
Model Number:
-
MTS-203,XT-11B,XT-23A
-
Max. Current:
-
15A
-
Mechanical Life:
-
500,0000 times above
-
Material:
-
Thermoplastic crust
-
Type:
-
Hand reset
Characteristics and Using:
• Adopt thermoplastic crust, compact construction, and simple installation;
• May install the protecting cap, can against oil and dustproof;
• Hand reset and automatic reset for flexible choice;
• Widely used in electricall equipment, automatic machine, communication equipment and instrument, electro motion tool etc
Specification:
|
Item |
Data |
|
|
Rating load |
15A/250VAC,25A/250VAC MTS:6A125,250V |
|
|
Operating frequency |
30times/min |
|
|
Insulation resistance |
100M Ω Above DC500V |
|
|
Contact resistance |
25m Ω initial value |
|
|
Withstand voltage |
Non-connection wire |
1000VAC |
|
Every terminal |
1500VAC |
|
|
Vibration |
Misoperation |
10-55Hz Amplitude 1.5mm |
|
Impact |
Durable |
1000m/s ² |
|
Misoperation |
300m/s ² |
|
|
Life |
Electrical |
100,000 above |
|
Mechanical |
500,000 above |
|
|
Protection degree |
IP40 |
|
|
Operating temperature |
-25~+80 ℃ |
|
|
Operating humidity |
< 85% |
|
Mounting Hole & Product Sructure:
Terminal Forms:
MTS-203 Dimension:
XT-11B Dimension:
XT-23A Dimension:
Our other toggle switch types:
