Quick Details
-
Brand Name:
-
GEYA
-
Model Number:
-
LGL-3P/4P 800A-1600A
-
Max. Current:
-
1600A
-
Dielectric strength (V):
-
3500
-
Rated impulse withstand voltage:
-
12Uimp (kV)
-
Rated working voltage Ue (V):
-
AC400,600
-
Rated frequency:
-
50Hz
-
Rated making capacity (A):
-
10le
-
Rated breaking capacity (A):
-
8le
-
Certification:
-
CB/CE/IEC
Quick Details
-
Whether the smart:
-
Yes
-
Max. Voltage:
-
1000V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
GEYA
-
Model Number:
-
LGL-3P/4P 800A-1600A
-
Max. Current:
-
1600A
-
Dielectric strength (V):
-
3500
-
Rated impulse withstand voltage:
-
12Uimp (kV)
-
Rated working voltage Ue (V):
-
AC400,600
-
Rated frequency:
-
50Hz
-
Rated making capacity (A):
-
10le
-
Rated breaking capacity (A):
-
8le
-
Certification:
-
CB/CE/IEC
Product Description
GEYA LGL-3P 800A-1600A Wholesale High Quality Automatic Electrical Blade Fuse Knife Switch
This link price is only for LGL-1000/3P 800A-1000A. if you need other specification，please feel free to contact us！
Specification
|
Agreed heating current Ith
|
|
|
1000A
|
1250A
|
1600A
|
||||
|
Rated insulation voltage Ui (V)
|
|
|
1000
|
|
|
||||
|
Dielectric strength (V)
|
|
|
3500
|
|
|
||||
|
Rated impulse withstand voltage Uimp (kV)
|
|
|
12
|
|
|
||||
|
Rated working voltage Ue (V)
|
|
|
AC400、600
|
|
|
||||
|
Rated frequency
|
|
|
50Hz
|
|
|
||||
|
Use Category
|
|
|
AC-21、22、23
|
|
|
||||
|
Rated working current le (A) |
AC440V
|
AC-21
|
1000
|
1250
|
1600
|
||||
|
|
|
AC-22
|
1000
|
1250
|
1600
|
||||
|
|
|
AC-23
|
800
|
1000
|
1250
|
||||
|
|
AC660V
|
AC-21
|
1000
|
1250
|
1600
|
||||
|
|
|
AC-22
|
630
|
630
|
800
|
||||
|
|
|
AC-23
|
250
|
400
|
500
|
||||
|
Rated making capacity (A)
|
|
|
10le
|
|
|
||||
|
Rated breaking capacity (A)
|
|
|
8le
|
|
|
||||
|
Rated short-circuit making capacity Icm (kA)
|
|
|
70
|
|
|
||||
|
1s short-time withstand current Icw (kA)
|
|
|
50
|
|
|
||||
|
Mechanical life (times)
|
|
|
2000
|
|
|
||||
|
Electrical life (times)
|
|
|
300
|
|
|
||||
|
Operating torque (N.m)
|
|
|
27
|
|
|
||||
|
Weight kg (excluding handle)
|
|
3P
|
10.5
|
10.5
|
16
|
||||
|
|
|
4P
|
13
|
13
|
20
|
||||
