Quick Details
Quick Details
-
Use:
-
Vehicles & Remote Control Toys
-
Place of Origin:
-
China
-
Model Number:
-
46FOV 1080P
Product Description
Product Specification
HDZero Goggle was designed with the FPV community for the FPV community. We asked what you wanted, and we delivered:
* Open-source goggle software and CAD files, so you can customize it to your preferences
* Clear digital video immune to warping, color shifting, and image rolling
* 1080p 90hz adaptive refresh rate OLED micro-displays
* Resolutions for different flying types: 1080p30, 720p60, 540p90, and 540p60
* Smoothest and fastest link for the most connected flying feel (3ms glass-to-glass)
* Fly with friends – 1-way broadcast doesn't interfere with nearby pilots
* Improved analog video resolution with real-time deinterlacer
* All the video input and output you need – one goggle for digital, analog, and HDMI video * Analog 3.5mm AV input
* HDMI input and output (yes, it is
possible to have both)
* Headphone/microphone combo jack
* Add-on Analog Module Bay with 2.4Ghz Wi-Fi module for future expansion: * Video streaming to phone (possible future capability)
* OTA Goggle FW updates (possible future capability)
* Mount antennas to innovative rail mount system
Features:
* On/off sliding switch – be confident that the goggle is on or off at a glance or by feel
* Designed for open source, the new goggle runs Linux. All code for the user interface is new and open source
* Support diopter lens inserts
* 90Hz 1080p OLED screens with sliding IPD adjustment and dials for focus adjustment
* By integrating the entire goggle display pipeline with HDZero's fixed-latency video transmission, these goggles achieve 3ms
glass-to-glass sub-frame latency with no jitter or dropped frames
* Mounting rails for patch antennas or whatever else you might want to mount
* Recessed front SMA jacks so no need to remove antennas when packing the goggle away
* Three independently addressable fans work in combination to cool the internals and prevent fogging. They are soft mounted to
prevent screen vibration and noise
* HDMI input and HDMI output
* Built-in microphone for DVR
* 3.5mm combination headphone / microphone jack for audio and external mic
* 3.5mm analog video/audio input for use with ground station inputs
* Integrated 2D deinterlacer that adds no delay for analog input
* Built-in ESP32
* Built-in H.265 DVR
* 6-axis smart inertial measurement for head tracking pan+tilt support
* Add-on side-mounted analog module bay that accepts most of today's analog modules
* Add-on 2.4Ghz WiFi video streaming module for live steaming
Specification:
* HDZero Camera glass-to-goggle glass latency: <3ms
* Adjust IPD range: 57-70mm
* Adjustable focus range: +6 to -6 diopter
* Full HD 1920x1080p 90fps OLED micro display
* FOV: 46deg
* Input voltage: 7V-25.2V
Includes:
* 1x HDZero goggle
* 1x wide face plate
* 1x narrow face plate
* 1x foam padding
* 1x Goggle Strap
* 1x 1200mm XT60 cable
* 1x 150mm HDZero VTX programing cable
* 1x Thick Canvas Goggle Bag
* 1x Lens cloth
* Open-source goggle software and CAD files, so you can customize it to your preferences
* Clear digital video immune to warping, color shifting, and image rolling
* 1080p 90hz adaptive refresh rate OLED micro-displays
* Resolutions for different flying types: 1080p30, 720p60, 540p90, and 540p60
* Smoothest and fastest link for the most connected flying feel (3ms glass-to-glass)
* Fly with friends – 1-way broadcast doesn't interfere with nearby pilots
* Improved analog video resolution with real-time deinterlacer
* All the video input and output you need – one goggle for digital, analog, and HDMI video * Analog 3.5mm AV input
* HDMI input and output (yes, it is
possible to have both)
* Headphone/microphone combo jack
* Add-on Analog Module Bay with 2.4Ghz Wi-Fi module for future expansion: * Video streaming to phone (possible future capability)
* OTA Goggle FW updates (possible future capability)
* Mount antennas to innovative rail mount system
Features:
* On/off sliding switch – be confident that the goggle is on or off at a glance or by feel
* Designed for open source, the new goggle runs Linux. All code for the user interface is new and open source
* Support diopter lens inserts
* 90Hz 1080p OLED screens with sliding IPD adjustment and dials for focus adjustment
* By integrating the entire goggle display pipeline with HDZero's fixed-latency video transmission, these goggles achieve 3ms
glass-to-glass sub-frame latency with no jitter or dropped frames
* Mounting rails for patch antennas or whatever else you might want to mount
* Recessed front SMA jacks so no need to remove antennas when packing the goggle away
* Three independently addressable fans work in combination to cool the internals and prevent fogging. They are soft mounted to
prevent screen vibration and noise
* HDMI input and HDMI output
* Built-in microphone for DVR
* 3.5mm combination headphone / microphone jack for audio and external mic
* 3.5mm analog video/audio input for use with ground station inputs
* Integrated 2D deinterlacer that adds no delay for analog input
* Built-in ESP32
* Built-in H.265 DVR
* 6-axis smart inertial measurement for head tracking pan+tilt support
* Add-on side-mounted analog module bay that accepts most of today's analog modules
* Add-on 2.4Ghz WiFi video streaming module for live steaming
Specification:
* HDZero Camera glass-to-goggle glass latency: <3ms
* Adjust IPD range: 57-70mm
* Adjustable focus range: +6 to -6 diopter
* Full HD 1920x1080p 90fps OLED micro display
* FOV: 46deg
* Input voltage: 7V-25.2V
Includes:
* 1x HDZero goggle
* 1x wide face plate
* 1x narrow face plate
* 1x foam padding
* 1x Goggle Strap
* 1x 1200mm XT60 cable
* 1x 150mm HDZero VTX programing cable
* 1x Thick Canvas Goggle Bag
* 1x Lens cloth
