Quick Details
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CB,CE,RoHS,PSE,EMC
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Enerlution
-
Model Number:
-
GroundHV-2600
-
Output Voltage (V):
-
51.2V
-
Output Frequency:
-
1680W
-
Work Time (h):
-
>6000.@25℃,0.5C,90%DOD
-
Product name:
-
LiFePO4 Battery Pack
-
Capacity:
-
48V 52Ah 2.5kWh/pack
-
Maximum Current:
-
35A
-
Voltage:
-
51.2V
-
Cycle life:
-
>6000 @25℃ 0.5C 90%DOD
-
Communication:
-
CAN/RS485
-
Battery cell:
-
A- Grade
-
Cell type:
-
Lifepo4 Rechargeable Battery Cell
-
Certification:
-
CB CE RoHS IEC62619 UN38.3 MSDS
-
Weight:
-
24kg
Quick Details
-
Application:
-
Home
-
Solar Panel Type:
-
Monocrystalline Silicon, Polycrystalline Silicon
-
Battery Type:
-
Lithium Ion
-
Controller Type:
-
MPPT
-
Mounting Type:
-
Ground Mounting
-
Certificate:
-
CB,CE,RoHS,PSE,EMC
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
Enerlution
-
Model Number:
-
GroundHV-2600
-
Output Voltage (V):
-
51.2V
-
Output Frequency:
-
1680W
-
Work Time (h):
-
>6000.@25℃,0.5C,90%DOD
-
Product name:
-
LiFePO4 Battery Pack
-
Capacity:
-
48V 52Ah 2.5kWh/pack
-
Maximum Current:
-
35A
-
Voltage:
-
51.2V
-
Cycle life:
-
>6000 @25℃ 0.5C 90%DOD
-
Communication:
-
CAN/RS485
-
Battery cell:
-
A- Grade
-
Cell type:
-
Lifepo4 Rechargeable Battery Cell
-
Certification:
-
CB CE RoHS IEC62619 UN38.3 MSDS
-
Weight:
-
24kg
Product Paramenters
|
GroundHV-2500
|
Enerlution home battery-- High voltage and low voltage High quality cells, self-brand BMS, easy installation.
Interface of Power Distribution Unit
Strong Battery Mangement System
Master control switch- restart battery system
Vehicle BMS--Non-industrial material: Components and Connectors come from the leading brands international
Main control chip from 'NXP', which meet the functional safety level certification of ASILB.
Using daisy chain communication technology, battery packs can be stacked flexibly. No order restrictions, meeting installation convenience and flexibility.
5 layers protection on batteries. Ground standing
Easy Installation
Wireless design
Embedded handle on each battery pack
Assemble pin interface
Connecting with Inverter
two power cables+ one single cable
Come with Dongle
30 Minutes for installation
|
Capacity
|
52Ah
|
|
Max. Discharge/Charge Current
|
35A
|
|
Battery Type
|
LiFePO4
|
|
Installation
|
Ground-mounted
|
|
Each Pack
|
23.5kg/220*580*170mm
|
|
PDU+Base
|
14kg/220*606*220mm
|
|
Protection Level
|
IP65
|
|
Cycle Life
|
>6000. @25℃，0.5C，90%DOD
|
|
Transportation SOC
|
30%
|
|
Working Temperature
|
Charge:0℃~+55℃ Discharge:-20℃~+55℃
|
|
Storage Temperature
|
-20°C~+35°C
|
|
Wi-Fi Module
|
optional
|
|
PDU/Pack Package Dimension
|
606*220*225mm
|
|
Mode
|
GroundHV-7.5K
|
GroundHV-10K
|
GroundHV-12.5K
|
|
Nominal Voltage
|
144V
|
192V
|
240V
|
|
Connection
|
1P45S
|
1P60S
|
1P75S
|
|
Voltage Working Range
|
114.7V-159.7V
|
153V-213V
|
153V-213V
|
|
Nominal Capacity
|
7.488kWh
|
9.984kWh
|
12.48kWh
|
|
Weight
|
~80kg/176lb
|
~105kg/231lb
|
~129kg/284lb
|
|
Dimension(W*H*D)
|
606*730*220mm
|
606*900*220mm
|
606*1070*220mm
|
|
Mode
|
GroundHV-15K
|
GroundHV-17.5K
|
GroundHV-20K
|
|
Nominal Voltage
|
288V
|
336V
|
384V
|
|
Connection
|
1P90S
|
1P105S
|
1P120S
|
|
Voltage Working Range
|
230V-319V
|
267.7V-372.7V
|
306V-426V
|
|
Nominal Capacity
|
14.976kWh
|
17.472kWh
|
19.968kWh
|
|
Weight
|
~152.3kg/335lb
|
~176.2kg/388lb
|
~199.5kg/438lb
|
|
Dimension(W*H*D)
|
606*1240*220mm
|
606*1410*220mm
|
606*1580*220mm
|
CAN.RS485
Our batteries are suitable for the vast majority of inverters in the market, and we have our own research and experimental personnel, as well as long-term non-stop inverter matching experiments for customers.
Strong Battery Mangement System
Master control switch- restart battery system
Vehicle BMS--Non-industrial material: Components and Connectors come from the leading brands international
Main control chip from 'NXP', which meet the functional safety level certification of ASILB.
Using daisy chain communication technology, battery packs can be stacked flexibly. No order restrictions, meeting installation convenience and flexibility.
.
GOTION A+ Grade battery Cell,More than 6000 cycle life @25℃ 0.5C
·Ground Mounted,Wall Mounted,High Voltage,2.5kWh-40kWh Lithium Ion Solar Battery
·Smart BMS built in 10 years warranty LiFePO4 battery for home solar energy storage with solar inverter
It supports capacity range from 7.5kWh to 20kWh, which completed by stack design with minimum 3packs+1 PDU, and Maximum 8packs+ 1
PDU. .Enerlution, Located in Hefei city, Anhui province ·European warehouse, Dubai warehouse, China warehouse
PDU. .Enerlution, Located in Hefei city, Anhui province ·European warehouse, Dubai warehouse, China warehouse
|
Global Exhibition
|
INTERSOLAR Germany 2023
INTERSOLAR Germany 2023a professional and famous PV Solar & BESS exhibition in the world which will be held in City Munich,
Germany from June 14th to16th 2023.
Germany from June 14th to16th 2023.
SNEC 2023 PV POWER EXP
a professional and famous PV POWER EXPO in Shanghai China.
Date: May 24-26th 2023
Date: May 24-26th 2023
Products Description
Product Feature
Smart O&M
Check the APP to find data on your phone.Remote diagnosis and OTA.
Expansion Flexibility
2.5kWh modular design ,Scalable from 7.5kWh to 20kWh.
Easy installation
24kg/52.9lb per battery box, easy to move and install. Quick connector between boxes, no cable connecting.
Safe & Reliable
Lithium Iron Phosphate(LFP) cell only. BMS, fuse and aerosol kit are built in.
Environment Adaptability
Wider temperature range: -20°C~+55°C. IP65 protection class.
Perfect Compatibility
Compatible to most high voltage inverters in the market.
More Usable Energy
90% Depth of Discharge, more than 6000 cycles (0.5C, 25℃). .
Enerlution & Certification
Certifications
Since its launch, the company's products have won the love of business leaders from various countries
Distributors from various countries have come to our factory for inspection and cooperation.
Fast Delivery
FAQ
Battery Cell
1： What battery cell you are using?
We are using Gotion or BYD brand new prismatic cell. If necessary, please contact us for battery cell specifications.
2： How many cycles can achieve for your battery cells?
BYD and GOTION brand new cells can achieve 6000 cycles @ 25℃, 0.5C conditions. Also please know usually 1C condition is only about 3500 cycles.
Low Voltage Battery
1：Which hybrid inverter your battery BMS has been communicated?
Our BMS has built protocol communication with most of inverter brands in market. You can please find the brnad information above picture.
High Voltage Battery
1：Which hybrid inverter your high voltage battery BMS has been communicated?
Our high voltage battery BMS has built protocol communication with Deye , afor. Growatt, Sofarsolar, Goodwe, INVT, Megarevo etc brand three phase hybrid inverters, You can please find the brnad information above picture or please contact us for new list.
2： Why we use high voltage battery?
High voltage battery always works with three phase hybrid inverters, which need a higher battery output. So we need high voltage battery solution to achieve a bigger kW power.
3： How much total voltage I need?
This depends on inverter battery side specifications. For three hybrid inverter, it is always around 150V to 600V. We just need to consider this HV battery system volatge is in this range.
Warranty
1：What's your warranty years?
The warranty period is ten years if the conditions are met. The product shall be free from material or workmanship defects for a period of ten years from the start date of the warranty.The product will be subject to usage restrictions based on the ambient temperature listed in the table below, and will operate in a normal manner according to the guidelines/specifications/warning labels provided by our company. After different years, there will still be 80% remaining usable power.
2：If battery has issues, how you proceed for warranty?
Our engineer will remotely check the issues by software, this need local installer assistance. If it is software issue, the
battery can be repaired by firmware update. If it is battery hardware issue, We provide replacement parts for customers to replace.
Service
1：Can you offer OEM or ODM?
Yes, we are LFP battery specialized solution provider mianly in energy storage field. You can please inform us your applications, inverter brand and model name. We will select or customize LFP battery system for you.
delivery date
1: How long can I ship the goods after I make the payment?
If it is not a customized version, we usually prepare some stock. We have 3 warehouses in Europe for hot selling items that can be picked up on the same day.
If it is an OEM, we need to ship from China and can ship it of 7-15 days; If it is ODM, it also needs to be designed and
customized from China, and then shipped, with a design cycle of 15-30 days.
after-sale service
1.What should I do if the product I received is damaged?
If the product is damaged upon receipt, we will provide you with a new item as soon as possible, without delaying your use or sale.
2.What assistance can I provide if I encounter difficulties during installation?
Our sales team provides detailed installation videos and instructions, as well as remote installation guidance throughout the entire process. We regularly organize installation guidance meetings in Europe and other places, provide face-to-face technical training, and provide free food and accommodation throughout the entire process.
3.What if I encounter quality issues with the product?
No matter what caused the problem and it is no usable, we will replace the battery with a new one from our warehouse in Europe as soon as possible. By the way, please rest assured that our product has not received any quality complaints for many years, and the probability of quality problems is currently very low.
4.What kind of sales assistance can I receive after purchasing?
If you are for sales purposes, we will provide a complete set of formal and valid certificates and authorize you to use them, provide high-definition images and promotional materials of the product, and provide free remote training for your sales and engineers.
1： What battery cell you are using?
We are using Gotion or BYD brand new prismatic cell. If necessary, please contact us for battery cell specifications.
2： How many cycles can achieve for your battery cells?
BYD and GOTION brand new cells can achieve 6000 cycles @ 25℃, 0.5C conditions. Also please know usually 1C condition is only about 3500 cycles.
Low Voltage Battery
1：Which hybrid inverter your battery BMS has been communicated?
Our BMS has built protocol communication with most of inverter brands in market. You can please find the brnad information above picture.
High Voltage Battery
1：Which hybrid inverter your high voltage battery BMS has been communicated?
Our high voltage battery BMS has built protocol communication with Deye , afor. Growatt, Sofarsolar, Goodwe, INVT, Megarevo etc brand three phase hybrid inverters, You can please find the brnad information above picture or please contact us for new list.
2： Why we use high voltage battery?
High voltage battery always works with three phase hybrid inverters, which need a higher battery output. So we need high voltage battery solution to achieve a bigger kW power.
3： How much total voltage I need?
This depends on inverter battery side specifications. For three hybrid inverter, it is always around 150V to 600V. We just need to consider this HV battery system volatge is in this range.
Warranty
1：What's your warranty years?
The warranty period is ten years if the conditions are met. The product shall be free from material or workmanship defects for a period of ten years from the start date of the warranty.The product will be subject to usage restrictions based on the ambient temperature listed in the table below, and will operate in a normal manner according to the guidelines/specifications/warning labels provided by our company. After different years, there will still be 80% remaining usable power.
2：If battery has issues, how you proceed for warranty?
Our engineer will remotely check the issues by software, this need local installer assistance. If it is software issue, the
battery can be repaired by firmware update. If it is battery hardware issue, We provide replacement parts for customers to replace.
Service
1：Can you offer OEM or ODM?
Yes, we are LFP battery specialized solution provider mianly in energy storage field. You can please inform us your applications, inverter brand and model name. We will select or customize LFP battery system for you.
delivery date
1: How long can I ship the goods after I make the payment?
If it is not a customized version, we usually prepare some stock. We have 3 warehouses in Europe for hot selling items that can be picked up on the same day.
If it is an OEM, we need to ship from China and can ship it of 7-15 days; If it is ODM, it also needs to be designed and
customized from China, and then shipped, with a design cycle of 15-30 days.
after-sale service
1.What should I do if the product I received is damaged?
If the product is damaged upon receipt, we will provide you with a new item as soon as possible, without delaying your use or sale.
2.What assistance can I provide if I encounter difficulties during installation?
Our sales team provides detailed installation videos and instructions, as well as remote installation guidance throughout the entire process. We regularly organize installation guidance meetings in Europe and other places, provide face-to-face technical training, and provide free food and accommodation throughout the entire process.
3.What if I encounter quality issues with the product?
No matter what caused the problem and it is no usable, we will replace the battery with a new one from our warehouse in Europe as soon as possible. By the way, please rest assured that our product has not received any quality complaints for many years, and the probability of quality problems is currently very low.
4.What kind of sales assistance can I receive after purchasing?
If you are for sales purposes, we will provide a complete set of formal and valid certificates and authorize you to use them, provide high-definition images and promotional materials of the product, and provide free remote training for your sales and engineers.
