Quick Details
-
Filling Accuracy:
-
99.8%
-
Voltage:
-
220/380/415V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Bievo
-
Dimension(L*W*H):
-
2600*1800*2100mm
-
Weight:
-
3500 KG
-
Suitable for:
-
Carbonated Soft Drink Line
-
Function:
-
Washing Filling Capping
-
Capacity:
-
2000-22000Bph
-
Processing Types:
-
Gas Drinks
-
Bottle type:
-
PET Plastic Bottle
-
Filling range:
-
330-1500ml
-
Applicable Cap Shape:
-
Plastic Screw Cap
-
Control:
-
PLC
-
Material:
-
Stainless Steel 304
-
Color:
-
Silver Gray
Quick Details
-
Machinery Capacity:
-
4000BPH, 8000BPH, 12000BPH, 6000BPH, 20000BPH, 16000BPH, 2000BPH
-
Packaging Material:
-
Plastic
-
Filling Material:
-
Beer, Other
-
Filling Accuracy:
-
99.8%
-
Voltage:
-
220/380/415V
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Bievo
-
Dimension(L*W*H):
-
2600*1800*2100mm
-
Weight:
-
3500 KG
-
Suitable for:
-
Carbonated Soft Drink Line
-
Function:
-
Washing Filling Capping
-
Capacity:
-
2000-22000Bph
-
Processing Types:
-
Gas Drinks
-
Bottle type:
-
PET Plastic Bottle
-
Filling range:
-
330-1500ml
-
Applicable Cap Shape:
-
Plastic Screw Cap
-
Control:
-
PLC
-
Material:
-
Stainless Steel 304
-
Color:
-
Silver Gray
Products Description
DGZ series filling machine - Washing filling capping 3-in-1
This series is applicable for carbonated beverage and beer filled in plastic bottles and capped with plastic caps,with optional capacity from 2000 BPH to 22000 BPH.
Product Paramenters
|
Model
|
DGZ
12-12-6
|
DGZ
18-18-6
|
DGZ
24-24-8
|
DGZ
32-32-8
|
DGZ
40-40-10
|
DGZ
50-50-12
|
DGZ
60-60-15
|
||||||
|
Production Capacity(bph)
|
2000-3000
|
3000-5000
|
6000-8000
|
8000-11000
|
12000-15000
|
15000-18000
|
18000-22000
|
||||||
|
Filling Pressure(Mpa)
|
≤0.4
|
|
|
|
|
|
|
||||||
|
Applicable Bottle Type
|
Bottle Diameter: Φ50-Φ100 mm Height: 150-320 mm Volume: 330-1500 ml
|
|
|
|
|
|
|
||||||
|
Applicable Cap Shape
|
Plastic Screw Cap
|
|
|
|
|
|
|
||||||
|
Gas Source Pressure(Amp)
|
0.6
|
0.6
|
0.6
|
0.6
|
0.6
|
0.6
|
0.6
|
||||||
|
Gas Consumption
(m3/min)
|
0.4
|
0.4
|
0.6
|
0.6
|
0.6
|
0.8
|
0.8
|
||||||
|
Total Power(kw)
|
4.6
|
5.4
|
6.4
|
8.5
|
11
|
12
|
15
|
||||||
|
Weight(kg)
|
2600
|
3500
|
5200
|
6500
|
8000
|
10000
|
12800
|
||||||
|
Dimension
(L*W*H)(mm)
|
2450*1650*2100
|
2600*1800*2100
|
3000*2200*2400
|
4000*2220*2400
|
4100*2700*2600
|
4500*3400*2600
|
5400*4100*2600
|
||||||
Details Images
1. Water Treatment System
Simple operation/Less maintenance/Lower power consumption.
The physical characteristics of water are filtered or treated so that water can be used directly for drinking or other purposes.
2. PET Bottle Blowing Machine
Less bottle cost/Stable working/High bottle performance.
The bottle blowing machine is for making plastic bottles.
3. Carbonated Beverage Filling Machine
High filling accuracy/Famous components/Stainless steel material.
DGZ series filling machine adopts the suspension design. It allows the machine to fill different type of the bottles. It is normally used as carbonated beverage filling machine. However, it can also be used for fill PET bottle with
beer
by simply change the accessories.
Washing Part
<1>Rinsing water distributor ensure each working position has stable water supply, as well as cut the rinsing water consumption.
<2>Single fluid spray nozzle is used, rinse water is spraying in setting angle, and clean all parts inside of bottle with features complete rinsing and water saving. Water rinsing time is 4 seconds and dripping water is 2 seconds;
Filling Part
<1>Material of filling valve and tank are made from stainless steel 304L.
<2>High speed and precision filling technology, liquid level precision ≤±2mm;.
<3>Circling liquid tank, the liquid level is controlled by floating ball.
Capping part
<1>High speed and high precision capping technology and ensure capping inferior ≤0.2%.
<2>Capping air tightness ≥ 99.99%
<3>Adopted in constant magnetic torque capping technology. capping effect is stable and reliable.
<4>The anti-rotation blade is made by chrome material, no rust and wearable.
4. Sleeve Labeling Machine
High precision/High speed.
According to customer request and market demand ,we provide the better solution for the final product package design.
5. Bottle Packing System
Better design for final package solution, more choice for label material.
We supply the different bottle package de
s
ign. Film package ,carton box wrapper, film with tray package and so on.
6. Pasteurized Tunnel Sterilizer
The pasteurization tunnel sterilizer is a necessary secondary sterilization equipment for automated production lines of dairy products, fruit juices, beverages, beer, food, pharmaceuticals, etc.
