Quick Details
-
Brand Name:
-
Multi-Tao
-
Dimension(L*W*H):
-
79330*1468*2219 (600 rotors)
-
Weight:
-
38000 KG
-
Power:
-
170kw (600 rotors)
Quick Details
-
Application:
-
Yarn spinning
-
Production Capacity:
-
10sets/month
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Multi-Tao
-
Dimension(L*W*H):
-
79330*1468*2219 (600 rotors)
-
Weight:
-
38000 KG
-
Power:
-
170kw (600 rotors)
Products Description
Tech specifications
|
Item
|
unit
|
Specifications
|
|
Rotor speed
|
r/min
|
40000~110000
|
|
Opening roller speed
|
r/min
|
5500~10000
|
|
Speed of guiding yarn
|
m/min
|
40~180
|
|
Rotor gauge
|
mm
|
230
|
|
No. of rotors
|
-
|
600 rotors, 20 rotors per section
|
|
Can dimension
|
mm
|
Φ400×900、Φ350×900
|
|
Dimension of bobbin
|
mm
|
Cylindrical Φ42/54×170；Conic Φ44/65×170
|
|
Package Specifications
|
mm
|
Φ300×150
|
|
Weight of per yarn
|
kg
|
≤4.5
|
|
Installed capacity of machine
|
kw
|
170 (based on number of rotors)
|
Technological Parameter
|
Item
|
Specifications
|
|
Raw materials
|
<60mm Natural and synthetic fibers
|
|
Sliver count range
|
6000tex~2500tex(30~12.5g/5m)
|
|
Draft range
|
20~280
|
|
Suitable No.
|
116tex~15tex(Ne6s~40s)
|
|
Winding angle
|
29~42°, Control panel infinite adjustment
|
|
Weight of per yarn
|
≤4.5kg
|
|
Type of rotor
|
33mm 34mm 36mm 42mm 50mm 54mm
|
|
Type of opening roller
|
Φ64mm
|
|
Type of Navel
|
Types of steel & ceramics naveal
|
