Quick Details
-
Model Number:
-
CP-47
-
Ambient temperature:
-
-25°C~65°C
-
Medium temperature:
-
-25°C~ 180°C
-
Electrical connection:
-
M20*1.5 sealing sleeve, G1/2, NPT1/2
Quick Details
-
Warranty:
-
1 year
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
CEOPA
-
Model Number:
-
CP-47
-
Ambient temperature:
-
-25°C~65°C
-
Medium temperature:
-
-25°C~ 180°C
-
Electrical connection:
-
M20*1.5 sealing sleeve, G1/2, NPT1/2
Product Description
| Caliber | DN25 | DN32 | DN40 | DN50 | DN65 | DN80 | DN100 |
| L sensor length | 92 | 95 | 115 | 144 | |||
| B (integrated shell height) | 107 | 117 | 128 | 137 | 156 | 167 | 192 |
| A (height of split shell) | 113 | 123 | 134 | 143 | 162 | 173 | 198 |
| d3 (Shell diameter) | 74 | 84 | 95 | 104 | 123 | 134 | 159 |
| d2 (chuck outer diameter) | 77.5 | 91 | 119 | 130 | 155 | ||
| d1 (sealing groove center) | 43.5 | 56.5 | 70.5 | 83.5 | 110 | ||
| d (sensor inner diameter) | 22.6 | 31.3 | 35.6 | 48.6 | 60.3 | 72.9 | 96 |
| Caliber | DN25 | DN32 | DN40 | DN50 | DN65 | DN80 | DN100 |
| L1 (installation length) | 156 | 159 | 199 | 228 | |||
| L (sensor length) | 92 | 95 | 115 | 144 | |||
| L2 (joint length) | 30 | 40 | |||||
| F (Outer diameter of connecting pipe) | 77.5 | 91 | 119 | 130 | 155 | ||
| E (DIN32676 joint inner diameter) | 26 | 32 | 38 | 50 | 66 | 81 | 100 |
| E (ISO2852 connector inner diameter) | 22.6 | 31.3 | 35.6 | 48.6 | 60.3 | 72.9 | 97.6 |
| d (joint inner diameter) | 22.6 | 31.3 | 35.6 | 48.6 | 60.3 | 72.9 | 96 |
