Quick Details
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
China
-
Brand Name:
-
Bailinshi
-
Model Number:
-
PC Solid sheet
-
Type:
-
Sun Sheets & PC Embossed Sheets
-
Color:
-
Customizable
-
Material:
-
Polycarbonate
-
Thickness:
-
0.7-15mm
-
Width:
-
Customized
-
Light transmitance rate:
-
Up to 12%-88%
-
Ultraviolet ray filter rate:
-
99%
-
Fire retardance:
-
Grade B2
-
Light weight:
-
With density of 1.20g/cubic centimeter
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Onsite Training
-
Project Solution Capability:
-
Others
-
Application:
-
Apartment
-
Design Style:
-
Modern
-
Place of Origin:
-
China
-
Brand Name:
-
Bailinshi
-
Model Number:
-
PC Solid sheet
-
Type:
-
Sun Sheets & PC Embossed Sheets
-
Color:
-
Customizable
-
Material:
-
Polycarbonate
-
Thickness:
-
0.7-15mm
-
Width:
-
Customized
-
Light transmitance rate:
-
Up to 12%-88%
-
Ultraviolet ray filter rate:
-
99%
-
Fire retardance:
-
Grade B2
-
Light weight:
-
With density of 1.20g/cubic centimeter
| Item | Width | Thickness | Weight | Min Curving Radius | Min Span Accordingly(mm) |
| (mm) | (mm) | (kg/m2) | (mm) | ||
| Polycarbonate solid sheet |
1220 1560 1820 2100 |
1.5 | 1.8 | 270 | 540 |
| 2 | 2.4 | 360 | 720 | ||
| 2.4 | 2.88 | 430 | 860 | ||
| 3 | 3.6 | 540 | 1080 | ||
| 3.8 | 4.56 | 680 | 1360 | ||
| 4 | 4.8 | 720 | 1440 | ||
| 5 | 6 | 900 | 1800 | ||
| 6 | 7.2 | 1080 | 2160 | ||
| 8 | 9.6 | 1450 | 2900 |
| PROPERTIES | UNI | VALUE |
| Density | g/cm | 1.2 |
| Light transmission | % | 88 |
| Impact strength | J/M | 850 |
| Flexural Strength | N/mm² | 100 |
| Tensile strength | N/mm² | ≥60 |
| Modulus of Elasticity | Mpa | 2400 |
| Tensile strength at break | Mpa | ≥65 |
| Elongation at break | % | >100 |
| Specific Heat Capacity | KJ/kg°K | 1.17 |
| Thermal Conductivity | W/m.K | 0.2 |
| Heat Deflection Temperature | ℃ | 140 |
| Coefficient of Linear Thermal Expansion | m/mm℃ | 0.067 |
| Service Temperature | ℃ | -40~120 |
| Acoustic Insulation | 10mm solid sheet | 33db |
Features
1) Light transmitance rate: up to 12%-88%, according to different colors
2) Ultraviolet ray filter rate: 99%,with ultraviolet-resistant co-extruded film on the surface
3) Impact strength: 250--280 times of the ordinary glass; 2 times of toughened glass; 20--30 times of PMMA sheet
4) Fire retardance: Grade B2, according to national GB8625-88 test
5) Sound insulation: can effectively resist the noise spread
6) Temperature resistance: not deform from -40 o C to +120 o C
7) Light weight: with density of 1.20g/cm³, easy to handle and drill; convenient for construction and procession
Specifications
1) Thickness: 0.7--15mm
2) Width: customized(maxmium width 2100mm)
3) Length: according to requirements
4) Color: transparent-blue, transparent-green, brown, opalescent
Note: All above are regular. We can also make offers according to requirements.
Applications
1) For resisting winds, rains, and gathering lights of all kinds of buildings, roofs, corridors, curtains, eaves of court yards.
2) For various advertising billboards, telephone stalls or ATM stalls.
3) For decoration of gardens, recreation rooms, or other public places.
4) For front shields or instruments and meter plants of cars, blats, planes, machines and police shields.
5) For sound-insulation walls of roads and bridges.
6) For raising sheds of crops, fruits and vegetables, animals and poultry,etc..
Our UV-PC solid sheets have UV-protective layer on one side or two sides, which prevents 99% harmful UV-ray, enhances its weather resistance and outdoor performance.
