- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
CF18801
-
Dimension:
-
Other
-
Power Supply Mode:
-
Other
-
Storage:
-
/
-
SNR:
-
/
-
Output Power:
-
Other
-
Connection Type:
-
Other
-
Shell Material:
-
Other
-
Format:
-
Other
-
The body material:
-
Other
-
Nominal diameter:
-
460mm/ 18 inch
-
Power rating:
-
1000-2000W
-
Nominal impedance:
-
8Ω
-
Sensitivity:
-
96dB
-
Frequency range:
-
40-1500Hz
-
Chassis type:
-
Cast aluminium
-
Voice coil diameter:
-
125mm/5in
-
Coil material:
-
SV-W
-
Number of layers:
-
2(Outside)
-
Former material:
-
ASV
Quick Details
-
Warranty:
-
Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
BM
-
Model Number:
-
CF18801
-
Dimension:
-
Other
-
Power Supply Mode:
-
Other
-
Storage:
-
/
-
SNR:
-
/
-
Output Power:
-
Other
-
Connection Type:
-
Other
-
Shell Material:
-
Other
-
Format:
-
Other
-
The body material:
-
Other
-
Nominal diameter:
-
460mm/ 18 inch
-
Power rating:
-
1000-2000W
-
Nominal impedance:
-
8Ω
-
Sensitivity:
-
96dB
-
Frequency range:
-
40-1500Hz
-
Chassis type:
-
Cast aluminium
-
Voice coil diameter:
-
125mm/5in
-
Coil material:
-
SV-W
-
Number of layers:
-
2(Outside)
-
Former material:
-
ASV
Products Description
|
Magnet type
|
Ferrite
|
|
Magnet Size
|
280X140X25mm
|
|
Magnet weight
|
5.16kg/182oz
|
|
Cone material
|
Paper
|
|
Surround material
|
Cloth
|
|
Spider
|
Double
|
|
X-max
|
7mm/0.28in
|
|
Gap depth
|
1 2mm/0.47in
|
|
Voice coil winding width
|
26mm/1.02in
|
|
Net Weight
|
18.6kg/pc
|
|
Packing Dimension WxDxH(mm)
|
488mmx488mmx250mm
|
|
Shipping Weight
|
20kg/ctn 1 pc/ctn
|
