Quick Details
-
Max Temperature:
-
1200℃
-
Working Temperature:
-
1100℃
-
Application::
-
Li-Ion Battery cathode material preparing
-
Temperature Controller:
-
51 Steps Programmable PID auto control
-
Temperature accuracy:
-
+/-1C
-
Heating Element::
-
Fe-Cr-Al-Mo Resistance Wire
-
Heating Rate:
-
20C/Minute(suggest <15C/Minutes
-
Chamber Material:
-
Alumina Ceramic Fiber
-
Chamber Size:
-
Dia60*L400mm
Quick Details
-
Brand Name:
-
Xinyu
-
Model Number:
-
XY-1200RTF-4
-
Place of Origin:
-
Henan, China
-
Max Temperature:
-
1200℃
-
Working Temperature:
-
1100℃
-
Application::
-
Li-Ion Battery cathode material preparing
-
Temperature Controller:
-
51 Steps Programmable PID auto control
-
Temperature accuracy:
-
+/-1C
-
Heating Element::
-
Fe-Cr-Al-Mo Resistance Wire
-
Heating Rate:
-
20C/Minute(suggest <15C/Minutes
-
Chamber Material:
-
Alumina Ceramic Fiber
-
Chamber Size:
-
Dia60*L400mm
1200.C electric laboratory rotary kiln for Li-Ion battery cathode material preparing
Brief Introduction:
1200.C electric laboratory rotary kiln is designed to get better temperature uniformity while calcining inorganic compound . especially excellent for preparing Li-lon battery cathode material with conductive coating.It can be leaned 30 degress and rotated 360 degress. the roate rate is 3 -7 round/minute and it also can rollbadk. The heating Zone also can be made in two zones.
The characteristics of 1200.C electric laboratory rotary kiln :
1: 51 Segments Programable and PID temperature controllor to make the operation more simple.
2:Furnace Chamber is made of Alumina caremic fiber to keep the better heat preservation .
3:Double shell with fan cooling to make the shell temperature close to the room temperature.
4: Intergrated doule circruit to make the furnace more safe , stable and realiable.
5:Humanized design and advaned technics to make the furnace more beautiful and durable.
6: Furnace Tube can be leaned 30 degress and rotated 360 degress.3-7 round/minute (can rollbadk)
7: The heating Zono also can be made in two zones.
Technical data of 1200.C electric laboratory rotary kiln :
| Model No# | XY-1200RTF-4 |
| Max. Temperature: | 1200℃ |
| Work Temperature: | 1100℃ |
| Chamber Material: | Light Alumina Carenmic Fiber |
| Temperature Control: |
51 Segments Programable and PID auto Control |
| Heating Element: | Fe-Cr-Al-Mo Wire |
| Furnace Structure: | Double Shell With fan Cooling |
| Thermal Couple: | K type(0-1200℃) |
| Heating Rate: | 20℃/Min(Suggest <15C/Minute |
| Temperature Accuracy: | +/-1℃ |
| Furnace Tube Size: | ø40/50/60/80/100mm |
| Heating Zone: | 200/300/450/600/800 mm |
| Furnace Tilt Angle | 0-30 degress |
| Rotating Speed: | 0-7 Rounds/Min(Can rollback) |
| Rated Power | 2.5KW |
| Standard Package: |
Tube Plug: 4 Pcs Thermocouple: 1 Pcs, Quartz Tube :1 Pcs, Vacuum Pump: 1 Set Sealing Flange :1 Pcs Vacumm Gauge: 1Pcs |
Accessories of 1200.C electric laboratory rotary kiln
1: Overseas service is available.
2: 1 Year quality warranty for whole furnace.
3: 3 Months free replacement for heating elements and cooling fan.
