Quick Details
-
Brand Name:
-
BIDOBON
-
Model Number:
-
BDBSC-001
-
Product name:
-
Stone Slab Lifting Clamp
-
Application:
-
Stone lifting
-
Type:
-
Stone Lifter Tools
-
Feature:
-
Endurance
-
Grip Range:
-
15mm-60mm
-
Mini Loading:
-
1000KG
-
Rubber color:
-
Black or White
-
Vertical Maximun:
-
260KG
-
Clamp Weight:
-
33KG
Quick Details
-
Measurement system:
-
Metric
-
Material:
-
Stainless steel, Metal, Rubber
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
BIDOBON
-
Model Number:
-
BDBSC-001
-
Product name:
-
Stone Slab Lifting Clamp
-
Application:
-
Stone lifting
-
Type:
-
Stone Lifter Tools
-
Feature:
-
Endurance
-
Grip Range:
-
15mm-60mm
-
Mini Loading:
-
1000KG
-
Rubber color:
-
Black or White
-
Vertical Maximun:
-
260KG
-
Clamp Weight:
-
33KG
The stone slab lifter application for material thicknesses of 15 to 60 mm, with the rubber linne jaws have been developed to handle material in slab or sheet form,stacked in racks, without damaging the material's surface. they have a number of advantages over common lifting devices.
The Stone slab Lifter with white rubber is an equipment for lifting and moving of slab-form materials(10-70mm). The Stone Lifter incorporates a spring-loaded latch that automatically releases the lifter from the slab once the slab has been fully lowered to the ground. The operating process becomes simple by one user's interaction only.
Features
- Compact structure allows the lifter lifts a bundle of slabs out of containers handily
- Size: possible to lift two slabs with different height concurrently
- Versatile: the slabs can be placed closely to the walls
- Safety: the operation is activated within simple actions to reduce the physical injuries for uses
Specifications
|
MODEL |
SIZES(mm) |
GRIP RANGE(mm) |
WEIGHT CAPACITY(kg) |
NET WEIGHT(kg) |
|
TLGW-50 |
250x170x350 |
0-50 |
1200 |
31 |
|
TLGW-70 |
250x190x350 |
30-70 |
1200 |
34 |
