Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Wintai-Tech Tact Switch
-
Model Number:
-
Tactile Switch TS-8080D
-
Product name:
-
Tactile Button Switch
-
Material:
-
PA66/Brass/Stainless steel
-
Mechanical Life:
-
200000cycles
-
Operating force:
-
160gf/250gf
-
Certification:
-
Reach, Rohs, ISO9001, TUV, CCC.
Quick Details
-
Protection Level:
-
IP67
-
Max. Current:
-
0.5A
-
Max. Voltage:
-
30VDC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Wintai-Tech Tact Switch
-
Model Number:
-
Tactile Switch TS-8080D
-
Product name:
-
Tactile Button Switch
-
Material:
-
PA66/Brass/Stainless steel
-
Mechanical Life:
-
200000cycles
-
Operating force:
-
160gf/250gf
-
Certification:
-
Reach, Rohs, ISO9001, TUV, CCC.
4Pin Waterproof
Tactile Switch
It is SMD/SMT 2pin mute type tactile switch, with 6.0mm x6.0mm in size, and from 4.3mm and 5mm knob height optional. There are four operating force options: 100gf, 160gf, 240gf, and 330gf.
The series tact switch has a life cycle of 300,000 to 500,000 actuations depending on the operating force and is electrically rated for 20mA of 15 VDC current.
With its small footprint, low profile, and SMT design, this ultra miniature tact switch can be used for many small applications,
Wearable technology and so on.
Product Paramenters
|
Product Name
|
Tactile Switch
|
|
Current Rating
|
50mA 30VDC
|
|
Travel
|
0.5±0.05mm
|
|
Operating Force
|
160gf, 250gf
|
|
Contact Resistance
|
100mΩ
|
|
Operating Temperature
|
-25oC ～ +80oC
|
|
Materials
|
Brass/PT66
|
|
Life Time
|
300,000 Cycles
|
Details Images
The circuits characteristics
PCB installation method
Products Description
Product Structure Description
Generally speaking, the universal touch switch is composed of 5 parts,
such as cover, pluger, contact dome,base and terminals, as shown on the right.
(1) The cover, is made of nickel-plated stainless steel plate. (2) The plunger, is made of nylon with black,red,yellow,green color optional. (3) The contact dome, is made of stainless steel plated silver. (4) Bass, is made of Nylon with black color. (5)Terminals，are made of brass.
(1) The cover, is made of nickel-plated stainless steel plate. (2) The plunger, is made of nylon with black,red,yellow,green color optional. (3) The contact dome, is made of stainless steel plated silver. (4) Bass, is made of Nylon with black color. (5)Terminals，are made of brass.
