Quick Details
-
Brand Name:
-
Huawei
-
Model:
-
S5735S-L48P4X-A1
-
Function:
-
LACP, POE, QoS, SNMP, Stackable, VLAN Support
-
Ports:
-
48
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
336Gbps/3.36Tb Ps
-
chassis height:
-
1U
-
Typical power:
-
41.7 W
-
fixed port:
-
24 10/100/ 1000Base-T
-
Flash memory:
-
512 MB
Quick Details
-
Type:
-
Enterprise Switch
-
Model Number:
-
S5735S-L48P4X-A1
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Huawei
-
Model:
-
S5735S-L48P4X-A1
-
Function:
-
LACP, POE, QoS, SNMP, Stackable, VLAN Support
-
Ports:
-
48
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
336Gbps/3.36Tb Ps
-
chassis height:
-
1U
-
Typical power:
-
41.7 W
-
fixed port:
-
24 10/100/ 1000Base-T
-
Flash memory:
-
512 MB
Product information
CloudEngine S5735-L series switches are designed for scenarios such as enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and powered by Versatile Routing Platform (VRP), CloudEngine S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols —providing higher performance and more powerful service processing capabilities for networks.
Features
Huawei
S5735S-L48P4X-A1
Silent Energy-Saving Design
Multiple energy-saving technologies, such as port dormancy, automatic port power adjustment, and fanless options achieve gigabit to the desktop in an energy-efficient way.
Simplified Network O&M
Super Virtual Fabric (SVF), with plug-and-play capabilities, virtualizes the core/aggregation switch, access switch, and Access Point (AP) into a single logical device for simplified network Operations and Maintenance (O&M).
Diversified Security Control
802.1X, Media Access Control (MAC) address, and Portal authentications, dynamically deliver user policies — Virtual Local Area Network (VLAN), Quality of Service (QoS), and Access Control List (ACL) — and also provide comprehensive mechanisms to fend off Denial of Service (DoS) and user-targeted attacks.
Multiple energy-saving technologies, such as port dormancy, automatic port power adjustment, and fanless options achieve gigabit to the desktop in an energy-efficient way.
Simplified Network O&M
Super Virtual Fabric (SVF), with plug-and-play capabilities, virtualizes the core/aggregation switch, access switch, and Access Point (AP) into a single logical device for simplified network Operations and Maintenance (O&M).
Diversified Security Control
802.1X, Media Access Control (MAC) address, and Portal authentications, dynamically deliver user policies — Virtual Local Area Network (VLAN), Quality of Service (QoS), and Access Control List (ACL) — and also provide comprehensive mechanisms to fend off Denial of Service (DoS) and user-targeted attacks.
Product Paramenters
|
Model Number
|
S5735S-L48P4X-A1
|
|
Typical power consumption [W]
|
41.7 W
|
|
Typical heat dissipation [BTU/hour]
|
142.29 BTU/hour
|
|
Maximum power consumption [W]
|
· Not providing the PoE function: 53.2 W
100% PoE loads: 433.2 W (PoE: 380 W) |
|
Maximum heat dissipation [BTU/hour]
|
· Not providing the PoE function: 181.52
100% PoE loads: 1478.12 |
|
MTBF [year]
|
55.72 year
|
|
MTTR [hour]
|
2 hour
|
|
Availability
|
>0.99999
|
|
Noise at normal temperature (acoustic power) [dB(A)]
|
50 dB(A)
|
|
Noise at normal temperature (acoustic pressure) [dB(A)]
|
38.2 dB(A)
|
|
Number of card slots
|
0
|
|
Number of power slots
|
0
|
|
Number of fans modules
|
2
|
|
Redundant power supply
|
Not supported
|
|
Long-term operating temperature [°C(°F)]
|
-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5906 ft.)
|
|
Short-term operating temperature [°C(°F)]
|
-5°C to +55°C (23°F to 131°F) at an altitude of 0-1800 m (0-5906 ft.)
|
|
Restriction on the operating temperature variation rate [°C(°F)]
|
When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the
altitude increases by 220 m (722 ft.). The equipment can operate beyond the normal operating temperature range for a short-term period, but the following conditions must be met: · The equipment operates at a temperature of over 50°C (122°F) consecutively for at most 96 hours in one year. · The equipment operates at a temperature of over 50°C (122°F) for a total of no more than 360 hours in one year. · The equipment operates at a temperature of over 50°C (122°F) for no more in 15 times in one year. The equipment may be damaged or experience unexpected exceptions if any of the preceding limits is exceeded. The equipment cannot start when the temperature is lower than 0°C (32°F). The maximum distance of optical modules used in these conditions cannot exceed 10 km. |
|
Storage temperature [°C(°F)]
|
-40°C to +70°C (-40°F to +158°F)
|
|
Long-term operating relative humidity [RH]
|
5% to 95%, noncondensing
|
|
Long-term operating altitude [m(ft.)]
|
0-5000 m (0-16404 ft.)
|
|
Storage altitude [m(ft.)]
|
0-5000 m (0-16404 ft.)
|
|
Power supply mode
|
AC built-in
|
|
Rated input voltage [V]
|
· AC input: 100 V AC to 240 V AC, 50/60 Hz
High-Voltage DC input: 240 V DC |
|
Input voltage range [V]
|
· AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz
High-Voltage DC input: 190 V DC to 290 V DC |
|
Maximum input current [A]
|
6 A
|
|
Memory
|
512 MB
|
|
Flash memory
|
512 MB
|
|
Console port
|
RJ45
|
|
Eth Management port
|
Not supported
|
|
USB
|
Not supported
|
|
RTC
|
Not supported
|
|
RPS input
|
Not supported
|
|
Service port surge protection [kV]
|
Common mode: ±7 kV
|
|
Power supply surge protection [kV]
|
±6 kV in differential mode, ±6 kV in common mode
|
|
Types of fans
|
Built-in
|
|
Heat dissipation mode
|
Heat dissipation with fan, intelligent fan speed adjustment
|
|
Airflow direction
|
Air intake from left and front, air exhaustion from right
|
|
PoE
|
Supported
|
|
Certification
|
EMC certification
Safety certification Manufacturing certification |
|
Console port
|
RJ45
|
|
Eth Management port
|
Not supported
|
|
USB
|
Supported
|
|
RTC
|
Not supported
|
|
RPS input
|
Not supported
|
|
Service port surge protection [kV]
|
Common mode: ±7 kV
|
|
Power supply surge protection [kV]
|
±6 kV in differential mode, ±6 kV in common mode
|
|
Types of fans
|
Built-in
|
|
Heat dissipation mode
|
Heat dissipation with fan, intelligent fan speed adjustment
|
|
Airflow direction
|
Air intake from left and front, air exhaustion from right
|
|
PoE
|
Not supported
|
|
Certification
|
EMC certification
|
|
|
Safety certification
|
|
|
Manufacturing certification
|
Product disply
