Quick Details
-
Full throttle operating rang:
-
4500-5500 r/m
-
Maximum Output:
-
11kw/15hp
-
Idling Speed:
-
1500±50r/m
-
Displacement:
-
139cc
-
Bore*Stroke:
-
56*50mm
-
Ignition System:
-
CDI
-
Spark Plug:
-
NGK B8HS-10
Quick Details
-
Product:
-
outboard engine for sale
-
Type:
-
2-stroke, 15hp
-
N.W(KG):
-
S:38kg;L:40kg;
-
Full throttle operating rang:
-
4500-5500 r/m
-
Maximum Output:
-
11kw/15hp
-
Idling Speed:
-
1500±50r/m
-
Displacement:
-
139cc
-
Bore*Stroke:
-
56*50mm
-
Ignition System:
-
CDI
-
Spark Plug:
-
NGK B8HS-10
Product:Outboard Engine For Sale
Type:2-stroke, 15hp
Specification
| Outboard Motor Model | TE15D |
| Net Weight | S:38Kg ; L: 40kg |
| Full Throttle Operating Range | 4500-5500 r/m |
| Maximum Output | 11kw/15hp |
| Idling Speed | 1050±50r/m |
| Type | Two Stroke |
| Displacement | 246cc |
| Bore*Stroke | 56*50mm |
| Ignition System | CDI |
| Spark Plug | NGK BR7HS-10 |
| Spark Plug Gap | 0.6-0.7mm |
| Control System | Tiller Handle |
| Starting System | Manual |
| Starting Carburation System | Choke Valve |
| Gear Position | Forward-Neutral-Reverse |
| Gear Ratio | 2.08 (27:13) |
| Trim and Tilt System | Manual Tilt |
| Recommended Fuel | Unleaded Gasoline |
| Gear Oil | 0.250L |
| Fuel Tank Capacity | 24L |
Certification
CE/SGS/ISO 9001
Advantages
-
Top cover more durable
- New design based on Japanese, easier for use
- High grade marine aluminum alloy for ultimate corrosion protection
- Tilt & trim with shallow water drive various positions
- Low oil indicator for increased protection
- Twist grip throttle control for easy maneuverability & safety
- Thermostat controlled water cooling system
- Safety lanyard with emergency shutoff
- Easy forward-neutral-reverse gear shifting
- Vibration reduction system for smooth performance
- Start in gear protection for increased safety
- Adjustable steering friction for easier maneuverability
- CDI ignition system for trouble free starting
- Innovative large recoil wheel assists easy starting
- Quiet, through the propeller hub exhaust
Product Series
We have both 4 and 2 stroke series, we also have 4 stroke propane engines which are more environment friendly. Almost plastic and die casting parts are made by ourselves, almost parts are made by Aluminum and treated by special surface treatment, so that we could control the quality serious, it is anti-corrosion and easy to carry.
OEM service
1% free spare parts
Warranty
1 year for commercial usage;
2 years for pleasure;
Package
Standard export package, carton box;
Port of Load
Ningbo, OR Shanghai
