Hantek DSO2C15 Digital Oscilloscope Dual Channel 150MHz Bandwidth Economical Oscilloscope

Product Name: Hantek DSO2C15 Digital Oscilloscope Dual Channel 150MHz Bandwidth Economical Oscilloscope

1) 2 channels which are respectively controlled by independent knobs

2) 100 MHZ and 150MHZ analog channel bandwidth

3) Sampling rate up to 1 GSa/s

4) 8M memory depth

5) Vertical range 2mV/div ~ 10V/div

6) Built-in 1 CH 25MHz waveform generator (DSO2D10, DSO2D15)

7) Vertical resolution: 8bit

8) Trigger: Edge, Pulse, Video, Slope, Overtime, Window, Pattern, Interval, Under Amp, UART, LIN, CAN, SPI, IIC

9) BUS decode and protocol analysis: RS232/UART, I2C, SPI, CAN, LIN

10) Can save multiple data formats, such as settings, waveforms, reference waveforms, CSV, pictures

11) A 3-digit digital voltage meter and a 6-digit hardware frequency indicator

12) 32 kinds of auto measurements with statistics, real-time statistics of maximum, minimum, standard deviation and etc.

13) 2 sets of digital voltmeters

14) Support threshold testing, free measurements within the screen

15) Abundant SCPI remote command control

16) USB Host/Device.

1CH 25MHz waveform generator, support arbitrary waveform burst output, support modulation waveform output

32 kinds of auto measurements with statistics

Can save 10 sets of reference waveforms, CSV waveforms and settings. The USB one-click screenshot function.

2 sets of DVM , 3-digit digital voltage meter and 6-digit hardware frequency indicator functions.

Serial bus trigger and decode , with the protocol monitoring function.

8M memory depth, r educing waveform distortion and restore real waveforms.

PASS/FAIL
