Quick Details
-
Warranty:
-
12 years
-
Model Number:
-
YC 655 PDF 66 G12/2
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
2384*1303*35 mm
-
Cell Type:
-
Mono
-
J-Box:
-
IP68,three diodes
-
Cable:
-
4mm²,positive 400mm/negative 200mm,length can be customized
-
Glass:
-
3.2mm tempered glass
-
Frame:
-
Anodized aluminum alloy
-
Weight:
-
33.9kg
-
Dimensions:
-
2384*1303*35mm
-
Packaging:
-
31 modules per pallet/18 pallets per 40' container
-
Power output:
-
655W
-
Module efficiency:
-
21.10%
-
Certificate:
-
CE/TUV
Quick Details
-
Cell size:
-
210mmx210mm
-
Type:
-
Half Cell, All Black
-
Panel Efficiency:
-
21.10%
-
Warranty:
-
12 years
-
Model Number:
-
YC 655 PDF 66 G12/2
-
Place of Origin:
-
Guangdong, China
-
Panel Dimensions:
-
2384*1303*35 mm
-
Cell Type:
-
Mono
-
J-Box:
-
IP68,three diodes
-
Cable:
-
4mm²,positive 400mm/negative 200mm,length can be customized
-
Glass:
-
3.2mm tempered glass
-
Frame:
-
Anodized aluminum alloy
-
Weight:
-
33.9kg
-
Dimensions:
-
2384*1303*35mm
-
Packaging:
-
31 modules per pallet/18 pallets per 40' container
-
Power output:
-
655W
-
Module efficiency:
-
21.10%
-
Certificate:
-
CE/TUV
|
Electrical parameters at Standard Test Conditions（STC）
|
|
|
|
|||
|
Module type
|
YC 655 PDF 66 G12/2
|
|
YC 530 PDF 55 G12/2
|
|||
|
Power output
|
Pmax
|
W
|
655
|
|||
|
Power output tolerances
|
ΔPmax
|
W
|
0/+5
|
|||
|
Module efficiency
|
ηm
|
%
|
21.10
|
|||
|
Voltage at Pmax
|
Vmpp
|
V
|
37.90
|
|||
|
Current at Pmax
|
Impp
|
A
|
17.31
|
|||
|
Open-circuit voltage
|
Voc
|
V
|
45.70
|
|||
|
Short-circuit current
|
Isc
|
A
|
18.40
|
|||
|
Electrical parameters at Nominal Operating Cell Temperature (NOCT)
|
|
|
|
|||
|
Power output
|
Pmax
|
W
|
655
|
|||
|
Voltage at Pmax
|
Vmpp
|
V
|
35.20
|
|||
|
Current at Pmax
|
Impp
|
A
|
14.05
|
|||
|
Open-circuit voltage
|
Voc
|
V
|
43.00
|
|||
|
Short-circuit current
|
Isc
|
A
|
14.83
|
|||
1.
Q: How can you guarantee quality?
A: We have a perfect pre-sales service and after-sales service system. We will start to track the whole process from the factory production, and there will be a service specialist to provide you with exclusive service, so as to ensure that there is no problem in the entire order process.
2. Q: Do you provide samples?
A: Yes, sample orders are welcomed.
2. Q: Do you provide samples?
A: Yes, sample orders are welcomed.
3.
Q: Do you provide OEM&ODM service?
A: Yes, we provide OEM&ODM service for most of our products. Please contact our sales manager for details.
4.
Q: What can you buy from us?
A: Solar Panel, BIPV, Solar cleaning robot, Battery, Portable power supply, and other solar energy products. If you have any needs, you can contact our sales managers. We will find the best solution for you.
5. Q: Are the products in stock?
5. Q: Are the products in stock?
A: For most products, we have inventory and will arrange delivery in time. For large orders, we will calculate the delivery time accordingly and communicate with you.
