·HT225 Integrated Schmidt hammer is a non-destructive testing and evaluation instrument for the compressive strength of hardened concrete in building structures.
·It can detect and record parameters such as rebound value, carbonization depth value angle, test surface and so on.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Lovely
-
Model Number:
-
HT225
-
Product name:
-
Concrete Test Hammer
-
Usage:
-
Strength Testing Machine
-
Standard Impact energy:
-
2.207J
-
Packing Details:
-
Standard export wooden case
-
Testing Range:
-
10~60Mpa
-
Stroke of rebound:
-
75mm
-
Friction of pointer slider:
-
0.5N~0.8N
-
Supply Ability:
-
40 Sets per Week
-
Certification:
-
ISO
Quick Details
-
Warranty:
-
1 year
-
Power:
-
Electronic
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
Lovely
-
Model Number:
-
HT225
-
Product name:
-
Concrete Test Hammer
-
Usage:
-
Strength Testing Machine
-
Standard Impact energy:
-
2.207J
-
Packing Details:
-
Standard export wooden case
-
Testing Range:
-
10~60Mpa
-
Stroke of rebound:
-
75mm
-
Friction of pointer slider:
-
0.5N~0.8N
-
Supply Ability:
-
40 Sets per Week
-
Certification:
-
ISO
Hot sale New Electronic rebound hammer digital concrete test hammer
Usage Overview
Product Description
·Special color screen display, automatic recording of detection time and date;
·The machine matches the national and local curves and can be set and selected by itself. · The parameters of angle, test surface, pumping and carbonization can be set on site.
·The machine matches the national and local curves and can be set and selected by itself. · The parameters of angle, test surface, pumping and carbonization can be set on site.
· Optional micro printer to print test results on site; · The upper computer software saves the data in Excel format, and can
directly generate word report format.
directly generate word report format.
Specification
|
Product name
|
HT-225 Concrete Test Hammer
|
|
Powder
|
Electronic
|
|
Standard Impact energy
|
2.207J
|
|
Testing Range
|
10~60Mpa
|
|
Stroke of rebound hammer
|
75mm
|
|
Friction of pointer slider
|
0.5N~0.8N
|
|
Sphere radius of rebound pole SR
|
25mm±1mm
|
|
Size
|
195x140x45mm
|
|
Weight
|
0.8KG
|
Our Advantages
Installation and training
·
If buyers visit our factory and check the machine, we will teach you how to installand use the machine, and also train your workers/technician face to face.
·
Without visiting, we will send you user manual and video to teach you to install and operate.
After Service
· One year guarantee for whole machine.
· 24 hours technical support by email or calling
Any questions, please contact me without hestitation, welcome your inquiry!Price can be negotiated
