Quick Details
-
Brand Name:
-
YARMEE
-
Model Number:
-
YC834
-
Input:
-
Condenser Microphone
-
Power supply:
-
DC24V(Supplied by the main unit)
-
Current drain:
-
40mA
-
Sensitivity:
-
-47dB
-
S/N:
-
65dB
-
Frequency response:
-
100-10KHZ
-
Weight:
-
1.1kg
-
Colors:
-
Silver/Gray Black
-
Installation:
-
Desktop
-
Length of gooseneck:
-
400mm
Quick Details
-
Type:
-
Audio Conference System, Video Conference System
-
Function:
-
Discussion&Video Tracking System
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YARMEE
-
Model Number:
-
YC834
-
Input:
-
Condenser Microphone
-
Power supply:
-
DC24V(Supplied by the main unit)
-
Current drain:
-
40mA
-
Sensitivity:
-
-47dB
-
S/N:
-
65dB
-
Frequency response:
-
100-10KHZ
-
Weight:
-
1.1kg
-
Colors:
-
Silver/Gray Black
-
Installation:
-
Desktop
-
Length of gooseneck:
-
400mm
YC834 Video Conference Microphone System
Features
- Mix discussion, camera tracking
- Teleconferencing is allowed with telephone coincidence
- Built in frequency shifting, restraining screaming
- The rack hole: fixed the main machine in the 19''standard rack
- Supports automatic camera tracking
- Tracking blackout remembering function, still tracking even breaking away from a computer
- The main machine has 4 route can connect 80 units, through extend power machine can connect 2000 units
- The computer and controlling the keyboard could bring about the function of automatic tracking video
- It has LCD display screen menu of Chinese and English. Bring about the control of the meeting function with the
- function-key
- Support Meeting Mode: Limit (1/2/3/4/5/6), FIFO (1/2/3/4/5/6), Chairman Only, AUTO
| NAME | YC834M Main Machine |
| Input/output | 8P-DIN×4 XLRM×1 RCA×1 6.35mm×1 |
| Input | RCA×1 |
| Power supply | AC220V-50HZ |
| Current drain | 120W(MAX) |
| Frequency response | 100-14KHZ |
| Weight | 8.5kg |
| Dimension(W.D.H) | 480×325×88mm |
| Colors | Dark gray |
Features
Match with 2.1M connection cable
With two microphone input design (adding the lapel microphone hub )
Built-in speaker, earphone jack and volume adjusting knob
Anti-interference from mobile phone
Chairman unit with priority speaking,can shut off each delegate speaking unit
Chairman can shut down all delegates, and chairmen do not be limited by main machine
Unit-direction condenser microphone: gooseneck microphone with red ring indicator LED
Open the microphone automatically mute speakers with headphone jack and volume control knob
Specifications
| NAME | YC834C/D MIC UNIT |
| Input/output | 8P-DIN×1(2M) |
| Input | Condenser Microphone |
| Power supply | DC24V(Supplied by the main unit) |
| Current drain | 40mA |
| Sensitivity | -47dB |
| S/N | 65dB |
| Frequency response | 100-10KHZ |
| Weight | 1.1kg |
| Dimension(W.D.H) | 190×130×56mm |
| Colors | Colors |
| Installation | Installation |
| Length of gooseneck | 400mm (Activity) |
