Quick Details
-
Model Number:
-
EF-VCT01
-
Function:
-
Medical Diagnosis
-
Application:
-
Hospital X-ray Room, Radiography Department, Veterinary cinic
-
Output Power:
-
50KW
-
Power Voltage:
-
380V±38V
-
kV range:
-
40~150kV
-
mA range:
-
10~630mA
-
mAs range:
-
0.1 ~630mAs
-
Exposure time:
-
0.002~6.3S
-
Inherent filtration:
-
1.0mm Al /75kV
Quick Details
-
Properties:
-
Disinfection Equipment
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Eachfine
-
Model Number:
-
EF-VCT01
-
Function:
-
Medical Diagnosis
-
Application:
-
Hospital X-ray Room, Radiography Department, Veterinary cinic
-
Output Power:
-
50KW
-
Power Voltage:
-
380V±38V
-
kV range:
-
40~150kV
-
mA range:
-
10~630mA
-
mAs range:
-
0.1 ~630mAs
-
Exposure time:
-
0.002~6.3S
-
Inherent filtration:
-
1.0mm Al /75kV
Product Description
Veterinary medical use IVIS Spectrum X Ray Computed Tomography 3D CT scanning system Analyzer CT scanning system Analyzer
Specification
|
High Frequency panoramic x-ray generator
|
|
|
|
|
|
Output Power
|
50KW
|
|
|
|
|
Power Voltage
|
380V±38V
|
|
|
|
|
kV range
|
40~150kV
|
|
|
|
|
mA range
|
10~630mA
|
|
|
|
|
mAs range
|
0.1 ~630mAs
|
|
|
|
|
Exposure time
|
0.002~6.3S
|
|
|
|
|
X-ray tube
|
|
|
|
|
|
Anode Heat Storage Capacity
|
240kHU
|
|
|
|
|
Small focus
|
0.6
|
|
|
|
|
Large focus
|
1.2
|
|
|
|
|
Anode speed
|
3000r/min
|
|
|
|
|
Collimator
|
|
|
|
|
|
Inherent filtration
|
1.0mm Al /75kV
|
|
|
|
|
Light Source
|
LED
|
|
|
|
|
Radiographic Table
|
|
|
|
|
|
Top Table Size
|
2100X800X650mm
|
|
|
|
|
Bucky Size
|
18X18inch
|
|
|
|
|
Table longitudinal movement
|
≥900mm
|
|
|
|
|
Cassette Movement Distance
|
≥500mm
|
|
|
|
|
Vertical Chest stand
|
|
|
|
|
|
Vertical moving range
|
≥1200mm
|
|
|
|
|
Bucky Size
|
18X18inch
|
|
|
|
|
Double Grid
|
|
|
|
|
|
Size
|
18X18inch
|
|
|
|
|
Ratio
|
1:1
|
|
|
|
|
F.D.
|
100cm
|
|
|
|
|
Density
|
40 L/cm
|
|
|
|
Features
:
1. Rich DR upgrade reserve interface
2. Fault self-diagnosis and protection
3. Automatic calibration of tube current
4. X-ray tube has the function of filament dormancy
5. AEC function, different ionization chamber as optional
6. Analog - digital double - loop control, simple operation, high intelligence
7. High kV, high current, high power,strong penetration,able to handle obese patients
