Quick Details
-
Max. Spindle Speed (r.p.m):
-
4500 r.p.m
-
Width of bed (mm):
-
30 mm
-
Spindle Motor Power(kW):
-
7.5
-
Travel (X Axis)(mm):
-
1000 mm
-
Travel (Z Axis)(mm):
-
400 mm
-
Place of Origin:
-
Guangdong, China
-
Dimension(L*W*H):
-
2180X1650X2050
-
Brand Name:
-
LICHI
-
Model Number:
-
LC-46X
-
Voltage:
-
380V/440V/220V/415V
-
Weight (KG):
-
3000
Quick Details
-
Type:
-
Horizontal
-
Max. Length of Workpiece (mm):
-
200
-
Year:
-
2023
-
Max. Spindle Speed (r.p.m):
-
4500 r.p.m
-
Width of bed (mm):
-
30 mm
-
Spindle Motor Power(kW):
-
7.5
-
Travel (X Axis)(mm):
-
1000 mm
-
Travel (Z Axis)(mm):
-
400 mm
-
Place of Origin:
-
Guangdong, China
-
Dimension(L*W*H):
-
2180X1650X2050
-
Brand Name:
-
LICHI
-
Model Number:
-
LC-46X
-
Voltage:
-
380V/440V/220V/415V
-
Weight (KG):
-
3000
Product Description
Specification
|
Processing efficiency (seconds/piece)
|
Time by product
|
|
Maximum rotation diameter
|
400mm
|
|
Maximum machining diameter
|
300mm
|
|
Maximum processing length
|
200mm
|
|
Spindle through hole diameter
|
Φ46mm
|
|
Spindle motor maximum speed
|
4000r/min
|
|
Spindle drive mode
|
Timing belt
|
|
X-axis travel
|
Two-way 1000mm
|
|
Z axis travel
|
400mm
|
|
X-axis/Z-axis maximum feedrate
|
25m/mim
|
|
positioning accuracy
|
±0.005
|
|
Repeatability
|
±0.003
|
|
Hydraulic station capacity
|
50L
|
|
Spindle motor power
|
7.5KW
|
|
X-axis/Z-axis motor power
|
1.7KW
|
|
External Dimensions (L*W*H)
|
2180X1650X2050mm
|
|
Total Weight
|
About 3000KG
|
Manufacturing Technique
Our Advantages
Title goes here.
Every year, we visit a large number of new and old products from Mexico, Russia,USA and other countries. High quality service, first-class technology to ensure that customers more trust, more efficient use of this product.
