Quick Details
-
Measuring Capacitance Range:
-
9.999mF
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZOYI ZOTEK
-
Model Number:
-
ZT111
-
Measuring Inductance Range:
-
/
-
Operating Temperature:
-
0~40℃
-
Dimensions:
-
130*65*32mm
-
Max. AC Voltage:
-
750V
-
Max. DC Voltage:
-
999.9V
-
Max. AC Current:
-
9.999A
-
Max. DC Current:
-
9.999A
-
low battery indicator:
-
/
-
Duty cycle:
-
1%~99%
Quick Details
-
Measuring Current Range:
-
9.999A
-
Measuring Voltage Range:
-
DC 999.9V/AC 750V
-
Measuring Resistance Range:
-
9.999MΩ
-
Measuring Capacitance Range:
-
9.999mF
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ZOYI ZOTEK
-
Model Number:
-
ZT111
-
Measuring Inductance Range:
-
/
-
Operating Temperature:
-
0~40℃
-
Dimensions:
-
130*65*32mm
-
Max. AC Voltage:
-
750V
-
Max. DC Voltage:
-
999.9V
-
Max. AC Current:
-
9.999A
-
Max. DC Current:
-
9.999A
-
low battery indicator:
-
/
-
Duty cycle:
-
1%~99%
Product Description
Specification
|
Technical Specifications
|
|
|
|
|
|
|||||
|
Function
|
Range
|
Resolution Ratio
|
Accuracy
|
Maximum measurement value
|
Frequency Response
|
|||||
|
DC Voltage（V)
|
999.9mV
|
0.1mV
|
±(0.5%+3)
|
999.9V
|
|
|||||
|
|
9.999V
|
0.001V
|
|
|
|
|||||
|
|
99.99V
|
0.01V
|
|
|
|
|||||
|
|
999.9V
|
0.1V
|
|
|
|
|||||
|
DC Voltage（mV)
|
9.999mV
|
0.001mV
|
|
99.99mV
|
|
|||||
|
|
99.99mV
|
0.01mV
|
|
|
|
|||||
|
AC Voltage（V)
|
999.9mV
|
0.1mV
|
±(1.0%+3)
|
750V
|
40Hz-1kHz
|
|||||
|
|
9.999V
|
0.001V
|
|
|
|
|||||
|
|
99.99V
|
0.01V
|
|
|
|
|||||
|
|
750V
|
1V
|
|
|
|
|||||
|
AC Voltage（mV)
|
9.999mV
|
0.001mV
|
|
99.99mV
|
|
|||||
|
|
99.99mV
|
0.01mV
|
|
|
|
|||||
|
DC Current(mA&A)
|
999.9mA
|
0.1mA
|
±(1.0%+3)
|
9.999A
|
|
|||||
|
|
9.999A
|
0.001A
|
|
|
|
|||||
|
DC Current(μA)
|
99.99μA
|
0.01μA
|
±(0.8%+3)
|
999.9μA
|
|
|||||
|
|
999.9μA
|
0.1μA
|
|
|
|
|||||
|
AC Current(mA&A)
|
999.9mA
|
0.1mA
|
±(1.2%+3）
|
9.999A
|
40Hz-1kHz
|
|||||
|
|
9.999A
|
0.001A
|
|
|
|
|||||
|
AC Current(μA)
|
99.99μA
|
0.01μA
|
±(1.0%+3)
|
999.9μA
|
|
|||||
|
|
999.9μA
|
0.1μA
|
|
|
|
|||||
|
Resistance
|
99.99Ω
|
0.01Ω
|
±(1.0%+3)
|
99.99MΩ
|
|
|||||
|
|
999.9Ω
|
0.1Ω
|
±(0.5%+3)
|
|
|
|||||
|
|
9.999kΩ
|
0.001kΩ
|
|
|
|
|||||
|
|
99.99kΩ
|
0.01kΩ
|
|
|
|
|||||
|
|
999.9kΩ
|
0.1kΩ
|
|
|
|
|||||
|
|
9.999MΩ
|
0.001MΩ
|
±(1.5%+3)
|
|
|
|||||
|
|
99.99MΩ
|
0.01MΩ
|
|
|
|
|||||
|
Capacitance
|
9.999nF
|
0.001nF
|
±(5.0%+20)
|
9.999mF
|
|
|||||
|
|
99.99nF
|
0.01nF
|
±(2.0%+5)
|
|
|
|||||
|
|
999.9nF
|
0.1nF
|
|
|
|
|||||
|
|
9.999F
|
0.001μF
|
|
|
|
|||||
|
|
99.99F
|
0.01μF
|
|
|
|
|||||
|
|
999.9μF
|
0.1μF
|
|
|
|
|||||
|
|
9.999mF
|
0.001mF
|
±(5.0%+5)
|
|
|
|||||
|
frequency
|
99.99Hz
|
0.01Hz
|
±(0.1%+2)
|
9.999MHz
|
|
|||||
|
|
999.9Hz
|
0.1Hz
|
|
|
|
|||||
|
|
9.999kHz
|
0.001kHz
|
|
|
|
|||||
|
|
99.99kHz
|
0.01kHz
|
|
|
|
|||||
|
|
999.9kHz
|
0.1kHz
|
|
|
|
|||||
|
|
9.999MHz
|
0.001MHz
|
|
|
|
|||||
|
Duty cycle
|
1%~99%
|
0.10%
|
±(0.1%+2)
|
|
|
|||||
|
Diode
|
√
|
|
|
|
|
|||||
|
on-off
|
√
|
|
|
|
|
|||||
|
NCV
|
√
|
|
|
|
|
|||||
|
Temperature
|
(-20~1000)℃
|
1℃
|
±(2.5%+5)
|
1000℃
|
|
|||||
|
|
(-4~1832)℉
|
1℉
|
|
1832℉
|
|
|||||
|
General technical indicators
|
|
|
|
|
|
|||||
|
display screen(LCD)
|
9999
|
|
|
|
|
|||||
|
range
|
Auto/Manual
|
|
|
|
|
|||||
|
material
|
ABS
|
|
|
|
|
|||||
|
Sample Rate
|
3 times/s
|
|
|
|
|
|||||
|
RMS
|
√
|
|
|
|
|
|||||
|
data hold
|
√
|
|
|
|
|
|||||
|
Screen backlight
|
√
|
|
|
|
|
|||||
|
Low battery warning
|
√
|
|
|
|
|
|||||
|
Automatic shutdown
|
√
|
|
|
|
|
|||||
|
Mechanical technical specifications
|
|
|
|
|
|
|||||
|
size
|
130*65*32mm
|
|
|
|
|
|||||
|
Weight (including battery)
|
114g
|
|
|
|
|
|||||
|
Power
|
1.5V AAA battery*2
|
|
|
|
|
|||||
|
Warranty period
|
one year
|
|
|
|
|
|||||
|
Environment
|
|
|
|
|
|
|||||
|
Work Environment
|
Temperature
|
0~40℃
|
|
|
|
|||||
|
|
Humidity
|
<75%
|
|
|
|
|||||
|
Storage Environment
|
Temperature
|
-20~60℃
|
|
|
|
|||||
|
|
Humidity
|
<80%
|
|
|
|
|||||
