4 Station 1 Color Automatic Slippers Screen Printer Carousel Screen Printing Machine For Shoes soles

4 Station 1 Color Automatic Slippers Screen Printer Carousel Screen Printing Machine For Shoes soles

FOB Reference Price: Get Latest Price

≥1 Pieces

US $5000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Guangdong, China

Brand Name:: Upart

Dimensions(L*W*H):: 1160 (L)X 950MM(W)X 1610MM(H)

Weight:: 580 KG

Certification:: CE Certification

Item Name:: 4 Station 1 Color Automatic Slippers Screen Printer

Printing color:: 1 color

Printing speed:: 1000 times/ hour

Max screen frame size:: 550x 700mm

Max printing area:: 280mm x 380mm

Worktable size:: 300mmx 450mm

Conveyor diameter:: 1250mm

Station quantity:: 4 pieces

Robot stroke:: 500mm

Quick Details

Condition:: New

Color & Page:: single color

Voltage:: 220V

Place of Origin:: Guangdong, China

Brand Name:: Upart

Dimensions(L*W*H):: 1160 (L)X 950MM(W)X 1610MM(H)

Weight:: 580 KG

Certification:: CE Certification

Item Name:: 4 Station 1 Color Automatic Slippers Screen Printer

Printing color:: 1 color

Printing speed:: 1000 times/ hour

Max screen frame size:: 550x 700mm

Max printing area:: 280mm x 380mm

Worktable size:: 300mmx 450mm

Conveyor diameter:: 1250mm

Station quantity:: 4 pieces

Robot stroke:: 500mm

4 Station 1 Color Automatic Slippers Screen Printer Carousel Screen Printing Machine For Shoes soles

Regards the video: please open this link on computer, then you can get it.

Product Description

i nstruction:

This machine speical design for insole printing and also apply to Mobile phone touch screen, light guide OGS / TP / CG / LTD glass, PCB, LCD, liquid green oil,EL, thin film, keyboard, acrylic, mobile phone panels, touch panels, light guide plate, diffusion chip, nameplate signs, ceramics, stationery and small pieces of film / sheet / Precision Screen Printing of the plate-shaped products, such as flexible printed circuit (FPC), in-mold decoration (IMD), film button (Membrane Switch), and other biological test piece ....... product precision flat screen printing.

4 Station 1 Color Automatic Slippers Screen Printer Carousel Screen Printing Machine For Shoes soles f eature:

1 The machine is pneumatic style, economical price with down load robot.

3 Printing holder with integrated pull aluminum molding, simple structure. Blade holder with cylinder with cross roller guide rail, smooth and stable, high precision.

4 Rotary table adopts Taiwan precision cam splitter drive, repeat positioning precision and speed swift, bench micrometer fine adjustment , vacuum suction platen, product positioning accuracy, prevent rotation during product loosening. One-piece cast aluminum wheel processing, structural stability, excellent rigidity, table flatness accuracy 0.05mm.

5 Robot laying-off:mechanical hands can be formulated material, reduce productivity, increase productivity, machines and production lines docking, cutting directly to the production line, according to customer requirements for non-standard custom.

6 The use of advanced control Mitsubishi PLC control, human-machine interface digital control, you can set a variety of functions and operating parameters, in favor of job data and standard equipment humane.

7 Installation of security bars, security screens, thorough operator personal safety protection;

8 Free oil drainage regulator group does not produce oil mist exhaust pollution, suitable for clean room use.

4 Station 1 Color Automatic Slippers Screen Printer Carousel Screen Printing Machine For Shoes soles parameter:

Item Number: US - 3045PD

1 Printing color: 1 color

2 Single Cycle: Can

3 Continue sports: can

4 Counter: can

5 Every parts delay time: can

6 Printing speed: 1 0 00 times/ hour

7 Max screen frame size: 5 50x 70 0mm

8 Max printing area: 280 mm x 38 0mm
