Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VEEPAI
-
Model Number:
-
C992DR
-
Resolution:
-
2MP
-
Lens:
-
3.6mm Fixed Lens
-
APP:
-
O-KAM PRO
-
Power Supply:
-
DC 5V 2A
-
Network:
-
Wifi 2.4Ghz
-
Night vision:
-
Auto IR-CUT
-
Storage:
-
Support Cloud Storage/TF Card( Max 256GB)
-
IR Distance:
-
8-12M
-
Audio:
-
Support 2-way Audio
-
Color:
-
WHITE
Quick Details
-
Special Features:
-
Human Motion Tracking, NIGHT VISION, Motion Detection, Sound Detection, PAN-TILT, Two-way Audio
-
Function:
-
Two-way Audio, PAN-TILT, Abnormal sound detection, RESET, Built-in Mic, NIGHT VISION, Wide Angle
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VEEPAI
-
Model Number:
-
C992DR
-
Resolution:
-
2MP
-
Lens:
-
3.6mm Fixed Lens
-
APP:
-
O-KAM PRO
-
Power Supply:
-
DC 5V 2A
-
Network:
-
Wifi 2.4Ghz
-
Night vision:
-
Auto IR-CUT
-
Storage:
-
Support Cloud Storage/TF Card( Max 256GB)
-
IR Distance:
-
8-12M
-
Audio:
-
Support 2-way Audio
-
Color:
-
WHITE
Products Description
Product Paramenters
|
Model #
|
|
C992DR
|
|
|
|||
|
Operating system
|
|
Embedded Linux
|
|
|
|||
|
Online visitors
|
|
Supports 4 visitors at the same time
|
|
|
|||
|
Image Sensor
|
|
1/3 inch 1440p progressive scan CMOS sensor
|
|
|
|||
|
Minimum illumination
|
|
0.5 Lux(Color mode), 0.1 Lux(B&W mode)
|
|
|
|||
|
Len
|
|
4mm-6mm
|
|
|
|||
|
Night Vision
|
|
Dual filter automatic switching,dual light source,illumination distance 15-30 meters.
|
|
|
|||
|
Compression standard
|
|
H.264 main profile/Motion-JPEG/JPEG
|
|
|
|||
|
Data rate
|
|
Main stream:1440p(2560×1440)@25fps,
Substream:360p(640×360)@15fps |
|
|
|||
|
Bit rate/maximum frame rate
|
|
128～4096kbps/25fps
|
|
|
|||
|
Image adjustment
|
|
Adjustable brightness and contrast
|
|
|
|||
|
Audio Input
|
|
Built-in -38dB microphone
|
|
|
|||
|
Audio Output
|
|
Built-in 8 Ω 1W speaker
|
|
|
|||
|
Audio Sampling frequency/bit width
|
|
8KHz/16bit
|
|
|
|||
|
Audio Compression standard/bit Rate
|
|
G.711/64kbps
|
|
|
|||
|
Network interface
|
|
10Mbps/100Mbps adaptive/RJ45 interface
|
|
|
|||
|
Network protocol
|
|
TCP/IP, HTTP, TCP, UDP, DHCP, DNS, NTP, RTSP, P2P etc.
|
|
|
|||
|
Wireless frequency
|
|
2.4G
|
|
|
|||
|
Pan&Tilt
|
|
Horizontal 350°/Vertical 90°
|
|
|
|||
|
Preset position
|
|
Supports 16 presets (mobile app only supports 5)
|
|
|
|||
|
Storage
|
|
Supports T-Flash card(max supports 256GB); Cloud Storage;NVR;NAS;
|
|
|
|||
|
Alarm detection
|
|
Supports motion detection, humanoid detection, human tracking, Voice and flash alarm, illumination function,timing white light
ON/OFF |
|
|
|||
|
Rated voltage
|
|
DC12V
|
|
|
|||
|
Power consumption
|
|
Rated power: 4.5W (infrared light on)/maximum power: 11W (pan&tilt on)
|
|
|
|||
|
Operating condition
|
|
Temperature: -10～50℃; Humidity: ＜90%
|
|
|
|||
|
Package size
|
|
Box size:90x90x185mm Carton:47x47x39.5cm 50pcs/Carton
|
|
|
|||
