Quick Details
-
Horsepower:
-
336hp
-
Cargo Tank Type:
-
Column plate
-
Gross Vehicle Weight:
-
11970
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Brand Name:
-
Oriemac
-
Place of Origin:
-
China
-
Size:
-
11200x2550x3980mm
-
Cargo Tank Dimension:
-
4200*2300*1050mm
-
Product name:
-
China 20/25ton LHD/RHD cargo truck mobile bar truck
-
Loading capacity:
-
25 Tons
-
Curb Mass:
-
11970kg
-
Front /rear overhang:
-
1500/3100mm
-
Max Speed:
-
95km/h
-
Engine Model:
-
WD615.69
-
Displacement:
-
9726
-
Container dimension L/W/H:
-
8300*2420*2500mm
Quick Details
-
Condition:
-
New
-
Emission Standard:
-
Euro 3
-
Market Segement:
-
Logistics transportation
-
Horsepower:
-
336hp
-
Cargo Tank Type:
-
Column plate
-
Gross Vehicle Weight:
-
11970
-
Drive Wheel:
-
6x4
-
After-sales Service Provided:
-
Onsite Installation, Video technical support, Overseas Call Centers, Return and Replacement, Field installation, commissioning and training, Online support, Free spare parts, Field maintenance and repair service
-
Brand Name:
-
Oriemac
-
Place of Origin:
-
China
-
Size:
-
11200x2550x3980mm
-
Cargo Tank Dimension:
-
4200*2300*1050mm
-
Product name:
-
China 20/25ton LHD/RHD cargo truck mobile bar truck
-
Loading capacity:
-
25 Tons
-
Curb Mass:
-
11970kg
-
Front /rear overhang:
-
1500/3100mm
-
Max Speed:
-
95km/h
-
Engine Model:
-
WD615.69
-
Displacement:
-
9726
-
Container dimension L/W/H:
-
8300*2420*2500mm
China 20/25ton LHD/RHD cargo truck mobile bar truck
HOWO brand new dump trucks 6x4 ZZ3257N3847A
6x4 right hand driving truck tipper
truck tipper for sale
A dump truck is a vehicle that unloads goods by itself through hydraulic or mechanical lifting. Also known as dump truck. It is composed of automobile chassis, hydraulic lifting mechanism, cargo compartment and force taking device.
The cars of dump trucks are divided into two kinds: backward tilting and side tilting. The movement of piston rod is controlled by the control system. Backward tilting is m ore common.
| General Specification | ||||
| Model | ZZ3257N3847A | |||
| Series | HOWO | |||
| Wheel Traction / Drive Style | 6X4 | |||
| Full Load Mass Weight | kg | 25000 | ||
| Curb Mass/ Self Weight | kg | 12270 | ||
| Steering Wheel Position | LHD/RHD | RHD (Right Hand Drive) | ||
| Engine | ||||
| Model | WD615.69 | |||
| Brand | SINOTRUK | |||
| Displacement | 9.726L | |||
| Type | In-line, Six-cylinder, Four-stroke, Water-cooled, Direct Injection, Intercooled Turbocharged Diesel Engine | |||
| Engine Classification / Standard | EURO II | |||
| Bore/Stroke | mm | 126/130 | ||
| Rated Horse Power | hp | 336 | ||
| Net Power | KW/rpm | 247KW/2200rpm | ||
| Torque (Nm/rpm): | Nm/rpm | 1350Nm @ 1100-1600rpm | ||
| Clutch & Gear Box Systems | ||||
| Clutch | SINOTRUK's 430 diaphragm spring clutch | |||
| Gear Box | SINOTRUK's HW19710 ,Manual Gearbox | |||
| Gear Speed/Lever | 10 forward/ 2 reverse | |||
| Gear Ratio |
14.28, 10.62, 7.87, 5.88, 4.38, 3.27, 2.43, 1.80, 1.34,
1.00, 13.91(R1), 3.18(R2) |
|||
| Axle & Steering | ||||
| Steering Model | ZF8098 | |||
| Front Axle | SINOTRUK's HF9 | |||
| Rear Axle | SINOTRUK's HC16 | |||
| Ratio of Rear Axle | 5.73 | |||
| Loading Capacity per Axle | front | 9000kg | ||
| rear | (2x) 16000kg | |||
| Brake System & Suspension | ||||
| Service Brake | dual circuit compressed air brake | |||
| Auxiliary Brake | engine exhaust valve brake | |||
| Parking Brake (Emergency Brake) | front | spring energy | ||
| rear | compressed air | |||
| Suspension Type | front | 10pcs leaf spring | ||
| rear | 12pcs leaf spring | |||
| Wheels & Tires | ||||
| Wheel Type | stud piloted 10 hole steel disc (20x8.50) | |||
| Number of Tires | 10+1 (spare tire) | |||
| Tire Type/Size | 12.00R20 | |||
| Track | front | 2022mm | ||
| rear | 1830mm | |||
