Quick Details
-
Voltage:
-
According to customer requirements
-
Power:
-
According to customer requirements
-
Dimension(L*W*H):
-
According to customer requirements
-
Weight (KG):
-
600
Quick Details
-
Place of Origin:
-
Shandong, China
-
Machine Type:
-
casting equipment
-
Brand Name:
-
xyc
-
Voltage:
-
According to customer requirements
-
Power:
-
According to customer requirements
-
Dimension(L*W*H):
-
According to customer requirements
-
Weight (KG):
-
600
Product Description
Specification
|
model
|
Z143
|
Z145
|
Z146
|
Z147
|
Z148WB
|
Z148WK
|
Z149
|
|
Maximum size of sand box（mm）
|
500*400
|
550*450*200
|
600*500*200
|
800*600*200
|
800*600
|
1000*630*300
|
1050*930*300
|
|
Table size（mm）
|
560*420
|
600*550
|
700*550
|
800*575
|
900*730
|
1200*730
|
1200*1030
|
|
Shock load（kgf）
|
250
|
300
|
400
|
400
|
600
|
1200
|
1200
|
|
Compressive strength（kgf）
|
4200
|
6300
|
7500
|
8000
|
10000
|
16000
|
16000
|
|
Compaction stroke（mm）
|
180
|
200
|
180
|
150
|
200
|
200
|
200
|
|
Draft stroke（mm）
|
160
|
180
|
200
|
220
|
250
|
300
|
350
|
|
efficiency（box/h）
|
40-60
|
40-60
|
40-60
|
40-60
|
40-60
|
40-60
|
40-60
|
|
Free air consumption（m³/box）
|
0.25
|
0.4
|
0.4
|
0.4
|
0.6
|
0.6
|
0.6
|
Packing & Delivery
PACKING: EXPORT PACKING:big parts on a wooden pallet and wrapping by film, single parts put together on wooden pallet and wrappingby film, precise parts packing by wood. (Packing woods are not recycled.) SHIPMENT MARK(S): On the surface of each package, a corresponding shipping mark in the English language shall be stenciled legiblyin fadeless or shipping labels tie on non-packing packages in the English language
