Quick Details
-
Brand Name:
-
Panda
-
Loading capacity:
-
6-10t
-
Specified Load:
-
Static load of 12 tons, moving load of 8 tons
-
Equipment Size(customizable):
-
L:2000mm, W:2000mm, H:600mm
-
Thickness and Length of the Base Plate:
-
14mm * 400mm (The whole plate pattern plate)
-
Main Board Thickness:
-
8mm pattern plate (Two pieces splicing)
-
Power of Motor:
-
Domestic ks pump station without solenoid valve (380v,50hz, 1.1KW )
-
Main Board Skeleton:
-
L-shaped bend piece,4mm thickness,number 12
-
Anti-collision Rubber:
-
Specification: L300 * W 200 * H100mm,belt stamping manufacturing
-
RAL Color (optional):
-
Black 9017; Gray 7016 ; Blue 5005
-
Spray Surface Treatment:
-
Steel sand spray after rust removal
Quick Details
-
Warranty:
-
1 Year
-
Weight (KG):
-
600
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Panda
-
Loading capacity:
-
6-10t
-
Specified Load:
-
Static load of 12 tons, moving load of 8 tons
-
Equipment Size(customizable):
-
L:2000mm, W:2000mm, H:600mm
-
Thickness and Length of the Base Plate:
-
14mm * 400mm (The whole plate pattern plate)
-
Main Board Thickness:
-
8mm pattern plate (Two pieces splicing)
-
Power of Motor:
-
Domestic ks pump station without solenoid valve (380v,50hz, 1.1KW )
-
Main Board Skeleton:
-
L-shaped bend piece,4mm thickness,number 12
-
Anti-collision Rubber:
-
Specification: L300 * W 200 * H100mm,belt stamping manufacturing
-
RAL Color (optional):
-
Black 9017; Gray 7016 ; Blue 5005
-
Spray Surface Treatment:
-
Steel sand spray after rust removal
Product Show
Dock Leveler Type
Folding dock Leveler
Telescopic dock Leveler
Product Details
The Hydraulic Platform
Standard size and pit size
|
Specification
|
Width of Platform
|
Length of Platform
|
Width of
Foundation Pits
|
Length of Foundation Pits
|
Height of Foundation Pits
|
|
2000 × 2000
|
2000mm
|
2000mm
|
2030mm
|
2000mm
|
610mm
|
|
2000 × 2300
|
2000mm
|
2300mm
|
2030mm
|
2300mm
|
610mm
|
|
2000 × 2500
|
2000mm
|
2500mm
|
2030mm
|
2500mm
|
610mm
|
|
2000 × 3000
|
2000mm
|
3000mm
|
2030mm
|
3000mm
|
610mm
|
|
2000 × 3500
|
2000mm
|
3500mm
|
2030mm
|
3500mm
|
610mm
|
|
2000 × 4000
|
2000mm
|
4000mm
|
2030mm
|
4000mm
|
610mm
|
|
Dynamic Load
|
Thickness of the Panel
|
Material for Thickening
|
Thickness of the Mouth Plate
|
Material of the Frame
|
Static Load
|
Weight of Sutable Forklifts
|
|
6 Ton
|
6 mm
|
4mm L-shaped steel
|
12x400
|
100 Channel Steels
|
8 Ton
|
2.5 Ton
|
|
8 Ton
|
8 mm
|
4mm L-shaped steel
|
14x400
|
100 Channel Steels
|
10 Ton
|
3 Ton
|
|
10 Ton
|
8 mm
|
14 # I-beam steel
|
16x400
|
100 Channel Steels
|
12 Ton
|
3.5 Ton
|
Telescopic Hydraulic Platform
Standard size and pit dimensions expansion length
|
Width of Platform
|
Length of Platform
|
Height of Platform
|
Width of
Foundation Pits
|
Length of Foundation Pits
|
Height of Foundation Pits
|
Telescopic Length
|
|
2000mm
|
2000mm
|
600mm
|
2030mm
|
2000mm
|
610mm
|
650mm
|
|
2000mm
|
2300mm
|
600mm
|
2030mm
|
2300mm
|
610mm
|
980mm
|
|
2000mm
|
2500mm
|
600mm
|
2030mm
|
2500mm
|
610mm
|
980mm
|
|
2000mm
|
3000mm
|
600mm
|
2030mm
|
3000mm
|
610mm
|
980mm
|
|
2000mm
|
3500mm
|
600mm
|
2030mm
|
3500mm
|
610mm
|
980mm
|
|
2000mm
|
4000mm
|
600mm
|
2030mm
|
4000mm
|
610mm
|
980mm
|
|
2000mm
|
5000mm
|
600mm
|
2030mm
|
5000mm
|
610mm
|
980mm
|
|
Dynamic Load
|
Thickness of the Panel
|
Material for Thickening
|
Thickness of the Mouth Plate
|
Material of the Frame
|
Static Load
|
Weight of Sutable Forklifts
|
|
6 Ton
|
6 mm
|
4mm L-shaped steel
|
14x400+8x700
|
100 Channel Steels
|
8 Ton
|
2.5 Ton
|
|
8 Ton
|
8 mm
|
4mm L-shaped steel
|
16x400+8x700
|
100 Channel Steels
|
10 Ton
|
3 Ton
|
|
10 Ton
|
8 mm
|
14 # I-beam steel
|
16x400+8x700
|
100 Channel Steels
|
12 Ton
|
3.5 Ton
|
|
14 Ton
|
10 mm
|
16 # I-beam steel
|
16x400+8x700
|
100 Channel Steels
|
16 Ton
|
3.5 Ton
|
Dock Leveler Color
Company Introduction
About Us
EXPORTING COUNTRY
Asia:
China、Thailand、 Malaysia、Indonesia、Singapore、Myanmar、Philippine、India、 Sri-lanka、Vietnam、UAE、Bahrain、F、Cambodia、Dubai、Pakistan、Mongolia、South Korea
Europe:
Poland、Russia、Holland、England、Norway、Germany、Swedish、ltaly、Denmark、Ukraine
South America:
Colombia、Brazil、Chile、Argentina、Brazil、Peru
North America:
Jamaica
Africa:
Nigeria、Angola、Luanda、South Africa、Zambia、Ghana
Oceania:
Australia、New Zealand
OUR CO-BRANDING
Payment & Delivery
FAQ
Q1：
Are you a trading company or a factory?
We are a Chinese Logistics equipment manufacturer.
We have our own production plant as the background and top three in the production scale in China. Have a strong technical team / R & D team. Our
products are very good in quality and competitive in price. So, they sell well.
Q2：
Can you do the full set products according to my project drawing?
Of course,
we have our own design parameters.
we can design and product the whole set Logistics equipment, also support all kinds of customization. If you need,
our engineer will check your project drawings to make sure its accuracy for each different fittings and quantity.
Q3：
Do you produce other products? Do you also produce accessories?
Yes, we also produce
various types of hydraulic platforms and loading
dock leveler,
mobile boarding bridge,
industrial
dock seal,
high speed PVC Door, l
ifting door, v
ehicle restraint, a
nti-collision block and other
logistics transportation
equipment; We produce parts by ourselves in order to control quality and cost.
Q4：
Can you give us a discount?
Because we have the most advanced production equipment, so in improving the quality of products but also effectively control the cost, you can buy at a very affordable price to your satisfaction.
If you need a large quantity or consider long-term cooperation, the price will be more favorable.
Q5：
How is the delivery time?
We will ship the goods after 25 working days after receiving the full payment.
