Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Leye
-
Model Number:
-
LY-A03-07
-
Feather:
-
Reflow solderable
-
Advantage:
-
Highly reliable contacts sealing structure
-
Quality:
-
Larger top surface of stem improves mounting speed
-
Rating:
-
50mA 12V DC
-
Insulation resistance:
-
100 MΩ min. 100V DC
-
Dielectric strength:
-
250V AC for 1 min.
-
Contact resistance:
-
50MΩ max.
-
Operating temperature range:
-
-30°c to + 85℃
-
Lifetime:
-
100,000 Cycles min.
-
Operating force:
-
B: 180gf C: 250gf
-
Certification:
-
rohs
Quick Details
-
Protection Level:
-
A
-
Max. Current:
-
50mA
-
Max. Voltage:
-
12V DC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Leye
-
Model Number:
-
LY-A03-07
-
Feather:
-
Reflow solderable
-
Advantage:
-
Highly reliable contacts sealing structure
-
Quality:
-
Larger top surface of stem improves mounting speed
-
Rating:
-
50mA 12V DC
-
Insulation resistance:
-
100 MΩ min. 100V DC
-
Dielectric strength:
-
250V AC for 1 min.
-
Contact resistance:
-
50MΩ max.
-
Operating temperature range:
-
-30°c to + 85℃
-
Lifetime:
-
100,000 Cycles min.
-
Operating force:
-
B: 180gf C: 250gf
-
Certification:
-
rohs
|
Rated Current
|
50mA
|
|
Rated Voltage
|
12V
|
|
Contact Resistance
|
≤100mΩ Max
|
|
Insulation Resistance
|
≥100mΩ 100V DC
|
|
Compressive Strength
|
AC250V 50Hz/1min
|
|
Mechanical Life
|
50000 cycles min
|
|
Operating Stroke
|
0.2±0.05mm
|
|
Operating Force
|
160gf/260gf±50gf
|
|
Temperature Range
|
-25℃~+70℃
|
