Quick Details
-
Model Number:
-
S6022
-
Operating Temperature:
-
-30~120
-
Certification:
-
CE
Quick Details
-
Media Type:
-
Liquid
-
Place of Origin:
-
China
-
Brand Name:
-
Soloon
-
Model Number:
-
S6022
-
Operating Temperature:
-
-30~120
-
Certification:
-
CE
|
Rated voltage V Rated Current A |
Power COS ø |
125VAC |
250V AC |
|
|
No induced load current |
1 |
15 |
15 |
|
|
Induced load |
Full load current |
0.75 |
3.5 |
2.5 |
|
Current |
Instantaneous current |
0.45 |
21 |
15 |
|
Valve Size |
Connector |
Max Pressure (Mpa) |
Protection |
Allowable Medium Temp. |
Wet. (Kg) |
Modulating Range of Flow |
||||
|
3″
|
1″-11½ (NPT)
|
1.60
|
IP65
|
-30~120
|
0.6
|
Pipe Size |
Min. |
Max. |
||
|
|
Flow decrease |
Flow increase |
Flow decrease |
Flow increase |
||||||
|
1″ |
2.5 |
4.2 |
8.5 |
8.8 |
||||||
|
2″ |
9.5 |
13.7 |
27 |
29 |
||||||
|
3″ |
19 |
27.5 |
50 |
53 |
||||||
Flow Rate
When there is sufficient fluid through the pipe, the loop closes up between red and blue contacts.
