Quick Details
-
Dimension(Long * Breadth * High):
-
6800X2040X2850 mm
-
Machine Weight:
-
19500 kg
-
Bucket capacity:
-
4m3, 4m3
-
Marketing Type:
-
New Product 2023
-
Model:
-
LT968
-
Keyword:
-
front end wheel loader
-
Operating weight:
-
19500kg
-
Rated loading capacity:
-
6000kg
-
Wheel base:
-
2760mm
-
Dumping height:
-
3180mm
-
Dumping reach:
-
1250mm
-
Overall dimensions:
-
7600*3000*3350mm
-
Rated power:
-
162KW/2200r/min
Quick Details
-
Engine Brand:
-
famous brand
-
Power:
-
178KW
-
Place of Origin:
-
China
-
Dimension(Long * Breadth * High):
-
6800X2040X2850 mm
-
Machine Weight:
-
19500 kg
-
Bucket capacity:
-
4m3, 4m3
-
Marketing Type:
-
New Product 2023
-
Model:
-
LT968
-
Keyword:
-
front end wheel loader
-
Operating weight:
-
19500kg
-
Rated loading capacity:
-
6000kg
-
Wheel base:
-
2760mm
-
Dumping height:
-
3180mm
-
Dumping reach:
-
1250mm
-
Overall dimensions:
-
7600*3000*3350mm
-
Rated power:
-
162KW/2200r/min
Products Description
|
Model
|
LT955
|
LT966
|
LT968
|
LT978
|
LT988
|
|
Rated power
|
162KW/2200r/min
|
175KW/2200r/min
|
178KW/2200r/min
|
199KW/2200r/min
|
247Kw/2200r/min
|
|
Overall dimensions
|
7600*3000*3350mm
|
8250*3210*3640mm
|
8700*3100*3670mm
|
8600*3230*3800mm
|
9100*3200*3640mm
|
|
Operating weight
|
16500KGS
|
19500KGS
|
19500KGS
|
24300KGS
|
25300KGS
|
|
Rated loading capacity
|
5000KGS
|
6000KGS
|
6000KGS
|
7000KGS
|
8000KGS
|
|
Bucket capacity
|
3m³
|
4m³
|
4m³
|
4~6m³
|
5.5~7m³
|
|
Bucket width
|
3000mm
|
3210mm
|
3160mm
|
3300~3500 mm
|
3520mm
|
|
Wheel base
|
2760mm
|
3200mm
|
3100mm
|
3380mm
|
3350mm
|
|
Dumping height
|
3180mm
|
3750mm
|
3600mm
|
3460mm
|
3550mm
|
|
Dumping reach
|
1250mm
|
1300mm
|
1300mm
|
1300mm
|
1300mm
|
|
Turning angle
|
35°± 1°
|
35°± 1°
|
35°±1°
|
35°±1°
|
35°±1°
|
|
Max.climbing Gradient
|
28°
|
28°
|
28°
|
30°
|
28°
|
|
Turning radius
|
6650mm
|
7470mm
|
7134mm
|
7400mm
|
7470mm
|
|
Max.breakout forth
|
145kN
|
175kN
|
175kN
|
202kN
|
175kN
|
|
Max.torque
|
745.3N.m
|
1000N.m
|
1000N.m
|
186kN
|
1350N.m
|
|
Lifting time
|
≤6.8s
|
≤6.8s
|
≤6.5s
|
≤6.5s
|
≤6.5s
|
|
Hydraulic cylinder time
|
≤12.55s
|
≤10.5s
|
≤10.5s
|
≤12s
|
≤10.5s
|
|
Specification of tire
|
23.5-25
|
26.5-25
|
26.5-25
|
26.5R25
|
26.5R25
|
Feature
1.
Multifunctional workbench
Multifunctional steering wheel, flexible steering and comfortable control
2.
Large capacity bucket
Large-capacity bucket, fast working speed and higher efficiency
3.
Hydraulic lifting rod
Two-in-one joystick, more convenient operation
4.
Durable hydraulic parts
The front frame is installed with durable hydraulic control brand, and the operation is more sensitive
