Quick Details
-
Weight (KG):
-
350
-
Voltage:
-
220v
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JIN HUA TAI
-
Dimension(L*W*H):
-
900*1100*2100 mm
-
Machine Type:
-
Automatic Vertical Filling Packaging Machine VFFS
-
Machine Name:
-
Mechanical Jelly Bottle Shape Packaging Machine (High-end)
-
Packaged Item:
-
Jelly Packing
-
Packing Range:
-
10-30 g
-
Packing Film Material:
-
Laminated Film,OPP/CPP, PET/PE,etc.
-
Bag Size:
-
L:50-60 mm W:40-90 mm
-
Packing Speed:
-
45-55 Bag/Min
-
Control System:
-
PLC+touch Screen
-
Filling System:
-
Pump
-
Feature:
-
No Leakage & High Reliability, High Efficiency
Quick Details
-
Function:
-
FILLING, Wrapping, Sealing, counting, Weighing
-
Packaging Type:
-
Bags, Film, Foil, Pouch, Sachet
-
Packaging Material:
-
Plastic, Paper, Wood
-
Weight (KG):
-
350
-
Voltage:
-
220v
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
JIN HUA TAI
-
Dimension(L*W*H):
-
900*1100*2100 mm
-
Machine Type:
-
Automatic Vertical Filling Packaging Machine VFFS
-
Machine Name:
-
Mechanical Jelly Bottle Shape Packaging Machine (High-end)
-
Packaged Item:
-
Jelly Packing
-
Packing Range:
-
10-30 g
-
Packing Film Material:
-
Laminated Film,OPP/CPP, PET/PE,etc.
-
Bag Size:
-
L:50-60 mm W:40-90 mm
-
Packing Speed:
-
45-55 Bag/Min
-
Control System:
-
PLC+touch Screen
-
Filling System:
-
Pump
-
Feature:
-
No Leakage & High Reliability, High Efficiency
APPLICATION & FEATURE
Jelly Bottle
Shape Packaging Machine (
Medium
)
◆APPLICATION
The machine is suitable for packing liquid materials which are used in food, chemical, medicine, condiment. Such as jelly, drink, oil, yogurt, etc.
◆FEATURE
1.
Useing pneumatic structure to seal, which is simple and easy to maintain;
2. The horizontal seal adopts two times of sealing. The first time is plain sealing, which there is no material left at the seal. The second time guarantees the flatness of the bag;
3. Between the two seals, the distance can be adjusted according to the bag length;
4. Multiple bag types can be customized, and the bag type is determined by punching and shearing die;
5. Seal tightly to avoid moisture;
6.
The pump body is made of whole food grade material, hygienic and durable;
7. New film feeding structure, higher accuracy.
MACHINE DETAIL
|
Product Name
|
Bottle Shape Jelly Packaging Machine (Medium / High)
|
|
Model
|
DF-50MPZ
|
|
Packaged Item
|
Jelly, Pudding
|
|
Driven Type
|
Mechanical
|
|
Sealing Type
|
Three-side Sealed
|
|
Filling System
|
Peristaltic Pump
|
|
Application
|
Food, Beverage, Medical, Chemical
|
|
Bag Type
|
Roll film sachet, pouch
|
|
Film Material
|
Composite Roll film: Metal(AL), Paper, OPP/CPP/PET/PE/PA/EVOH
|
|
Filling Range
|
10-30 g
|
|
Bag Size
|
L:50-60 mm W:40-90 mm
|
|
Packing Speed
|
45-55 Bag/Min
|
|
Voltage
|
220V 50/60HZ
|
|
Total Power
|
2.5 KW
|
|
Weight
|
350 KG
|
|
Machine Body
|
Stainless Steel SUS 304
|
|
Dimension (L*W*H)
|
900*1100*2100 mm
|
FINISHED PRODUCT
MORE HOT MODEL
COOPERATION BRAND
COMPANY PROFILE
Guangdong Jinhuatai Packaging Machine Technology Co., Ltd.
Guangdong Jinhuatai Packaging Machine Technology Co., Ltd. is a provincial private technology enterprise integrating the design, production and sales of food packaging equipment.
Since its establishment in 1999, the company has been committed to the R & D, production and sales of food and all kinds of packaging equipment. The products have been used in many fields such as food, washing and medical treatment. At present, there are offices in major large and medium-sized cities in China.
We sincerely welcome domestic and foreign enterprises to come to guide, seek cooperation and development together.
EXHIBITON & CERTIFICATE
Updated Exhibition:
◆ ProPak China 2019
◆ The 101th China Food & Drink Fair 2019
SERVICE & FAQ
Packaging:
We will clear every parts, packed firstly with the film, then put in the standard export wooden case ( Fumigation
Free).
Shipping:
Upon receipt of full payment , delivery date will be in 10-35 days. Shipment cost will depend on the destination, shipment way and the weight of the goods.
After-sale Services:
We will clear every parts, packed firstly with the film, then put in the standard export wooden case ( Fumigation
Free).
Shipping:
Upon receipt of full payment , delivery date will be in 10-35 days. Shipment cost will depend on the destination, shipment way and the weight of the goods.
After-sale Services:
1. Manuals / Videos of machine installation, adjusting, setting, maintenance are available for you.
2. If any problem happens and you can not find out the solutions, Telecom or Online face to face communication available 24 hours.
3. Engineers & technician are available send to your countries for services if you agree to pay the expenditure.
4. The machine will have one year warranty.
FAQ:
Q1: How to find a packaging machine suitable for my product?
Tell us about your product details and packing requirements.
1. Product details (Liquid,Powder,Granule etc.)
2. Bag shape and specification (Length, Width).
3. Packing film material.
4. Net weight of filling product.
Q2: How can I trust you for the first time business ?
We aim to establish a long-term cooperative relationship instead of just doing business once. If you don't trust us, then we can use Alibaba trade assurance service, guarantee your money, and guarantee your machine's on-time delivery and machine quality.
Q3: Is engineer available to serve oversea?
Yes, but the travel fee is paid by you.In order to save your cost, we will send you a video of full details machine installation and assist you till the end.
Q4. How can we make sure about the machine quality after placing the order?
Before delivery, we will send you the pictures and videos for you to check the machine quality.And also you can arrange for quality checking by yourself or by your contacts in China.
Q5: Can you explain me the whole transaction process ?
1. Sign the Contact;
2. Arrange 30% deposit to our factory;
3. Factory arrange production;
4. Testing & detecting the machine before shipping;
5. Inspected by customer or third agency through online or site test;
6. Arrange the balance payment before shipment.
