10ton 12ton heavy duty diesel forklift with duplex 3meter mast and fork positioner

10ton 12ton heavy duty diesel forklift with duplex 3meter mast and fork positioner

FOB Reference Price: Get Latest Price

≥1 Sets

US $44692.75

≥2 Sets

US $44232

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Fork Length:: 1520mm

Fork Width:: 175-180mm

Overall Dimensions:: 6220*2200*3080

Weight (KG):: 14500 kg

After Warranty Service:: Video technical support, Online support, Spare parts

Local Service Location:: Canada, Turkey, United Kingdom, United States, Viet Nam, Philippines, Mexico, Thailand, Malaysia, Argentina, Ukraine, Uzbekistan

After-sales Service Provided:: Video technical support

Certification:: CE, ISO

Marketing Type:: Hot Product 2019

Quick Details

Warranty:: 1 Year

Place of Origin:: Zhejiang

Brand Name:: FLIFT

Fork Length:: 1520mm

Fork Width:: 175-180mm

Overall Dimensions:: 6220*2200*3080

Weight (KG):: 14500 kg

After Warranty Service:: Video technical support, Online support, Spare parts

Local Service Location:: Canada, Turkey, United Kingdom, United States, Viet Nam, Philippines, Mexico, Thailand, Malaysia, Argentina, Ukraine, Uzbekistan

After-sales Service Provided:: Video technical support

Certification:: CE, ISO

Marketing Type:: Hot Product 2019

FLIFT Brand 10ton 12ton heavy duty diesel forklift with duplex 3meter mast and fork positioner

Product Description

FORKLIFT MODEL: FD100/FD120, MAST MODEL: M300.

FLIFT BRAND 10 ton Diesel forklift with Chinese Engine; load center: 600mm, Air Tyre,1520 mm Fork Length; Electrical Steering; Wide-view Duplex 3 Meter Mast; Fork positioner; Hydraulic Transmission. Operation & Service manual, Parts manual, Tool kit, Certificate of compliance. Cummins;

Standard configuration is without fullly closed cabin, which is optional.

Aire conditioner, fan heater, sideshifting for forks are optional,too.

FD100: Size(L*W*H): 4280 *2170*2830mm; Weight: 13000kg.

FD120: Size(L*W*H) : 4700 *2170*3080mm; Weight: 14500kg.

The length isn't includes the fork length.

1		Model	FD100		FD100	FD120	FD120
2		Power Type		Diesel	Diesel	Diesel	Diesel
3		Rated Capacity	kg	10000	10000	12000	12000
4		Load Centre	mm	600	600	600	600
5		Lift Height	mm	3000	3000	3000	3000
6	Fork Size	LxWxT	mm	1520x175x85	1520x175x85	1520x180x100	1520x180x100
7	Mast Tilt Angle	F/R	Deg	6/12°	6/12°	6/12°	6/12°
8	Front Overhang (Wheel Center to fork face)		mm	750	750	770	770
9	Ground Clearance (Bottom of mast)		mm	240	240	250	250
10		Length to face of fork(Without fork)	mm	4280	4280	4700	4700
11		Overall Width	mm	2170	2170	2200	2200
12	Overall Dimension	Mast Lowered Height	mm	2830	2830	3080	3080
13		Mast Extended Height(With backrest)	mm	4320	4320	4510	4510
14		Overhead Guard Height	mm	2570	2570	2590	2590
15	Turning Radius(outside)		mm	3970	3970	4700	4700
16		Min. insecting aisle	mm	3590	3590	4200	4200
17		Travel(Empty load)	km/h	30	30	28	28
18	Speed	Lifting(Full bad)	mm/s	270	270	280	280
19		Max. Gradeability	%	20	20	20	20
20	Tire	Front		9.00-20-14PR	9.00-20-14PR	9.00-20	9.00-20
21	Tire	Rear		9.00-20-14PR	9.00-20-14PR	9.00-20	9.00-20
22		Wheel Base	mm	2800	2800	3200	3200
23		Service Weight	kg	13000	13000	14500	14500
24	Battery	Voltage/Capacity	V/Ah	(12/80)x2	(12/80)x2	(12/80)x2	(12/80)x2
25		Model		6BG1	CA6110/125-HL10	QSB4.5-C130	6BT5.9-C130
26		Manufacturer		ISUZU	XICHAI	CUMMINS	DONGFENG CUMMINS
27		Rated output/r.p.m.	kw	82.3/2000	83/2000	97/2200	97/2200
28	Engine	Rated torque/r.p.m.	Nm	416/1400-1600	450/1400-1500	622/1500	560/1500
29	Engine	No. of Cylinder		6	6	4	6
30		Bore* Stroke	mm	105x125	110x125	107x124	102x120
31		Displacement	cc	6494	7127	4500	5900
32		Fuel Tank Capacity	L	140	135	150	150
33	Transmission	Type		Hydraulic	Hydraulic	Hydraulic	Hydraulic
34	Transmission	Stage FWD/RVS		2/2	2/2	2/2	2/2
35	Operating Pressure for Attachment		Mpa	19	19	19	19

Packaging & Shipping

To be fixed in the container by triangle wood/iron brackets withstand rough handling in the transit of forklifts.

The Nearest Port of Loading: Ningbo/Shanghai. it only takes 2hours to the port. Other Chinese ports are acceptable, too. Convenient, safe and fast Delivery!
