Quick Details
-
Brand Name:
-
HEYA/OEM
-
Model Number:
-
SDFII-6000-L
-
Input Voltage:
-
140V - 260V
-
Output voltage:
-
220V ± 8%
-
Frequency:
-
50Hz/60Hz
-
Certificate:
-
CE / ISO9001
-
Insulation resistance:
-
≥ 5(MΩ)
-
Color:
-
Customizable
-
operation temperature:
-
-15℃~45℃
-
Display:
-
LCD
-
Type:
-
Servo Motor Control
-
Application:
-
servo voltage stabilizer for generator, water pump, ligh
Quick Details
-
Phase:
-
Single Phase
-
Current Type:
-
AC
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HEYA/OEM
-
Model Number:
-
SDFII-6000-L
-
Input Voltage:
-
140V - 260V
-
Output voltage:
-
220V ± 8%
-
Frequency:
-
50Hz/60Hz
-
Certificate:
-
CE / ISO9001
-
Insulation resistance:
-
≥ 5(MΩ)
-
Color:
-
Customizable
-
operation temperature:
-
-15℃~45℃
-
Display:
-
LCD
-
Type:
-
Servo Motor Control
-
Application:
-
servo voltage stabilizer for generator, water pump, ligh
Products Description
Parameters
|
Model
|
SDFII-4000-L
|
SDFII-6000-L
|
SDFII-10000-L
|
SDFII-12000-L
|
||||
|
Nominal Power
|
4000VA
|
6000VA
|
10000VA
|
12000VA
|
||||
|
Power Factor
|
0.6-1.0
|
|
|
|
||||
|
Input
|
|
|
|
|
||||
|
Operating Voltage Range
|
120~275V
|
|
|
|
||||
|
Regulation Voltage Range
|
140~260V（custom made）
|
|
|
|
||||
|
Frequency
|
50HZ
|
|
|
|
||||
|
Connection Type
|
Input terminal block
|
|
|
|
||||
|
Output
|
|
|
|
|
||||
|
Operating Voltage
|
180~255V
|
|
|
|
||||
|
High Cut Voltage
|
255V
|
|
|
|
||||
|
Low Cut Voltage
|
180V
|
|
|
|
||||
|
Safety Cycle
|
8 Seconds / 180 Seconds (Optional)
|
|
|
|
||||
|
Frequency
|
50HZ
|
|
|
|
||||
|
Connection Type
|
Output terminal block
|
|
|
|
||||
|
Regulation
|
|
|
|
|
||||
|
Regulation %
|
1.5%/3.5%
|
|
|
|
||||
|
Number of Taps
|
NO
|
|
|
|
||||
|
Transformer Type
|
Toroidal auto transformer
|
|
|
|
||||
|
Regulation Type
|
Servo type
|
|
|
|
||||
|
Indicators
|
|
|
|
|
||||
|
LCD Display
|
Input voltage
Output voltage
Delay time
Load usage
Normal working
Temperature of transformer
Error code
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
|
|
|
|
|
||||
|
Protection
|
|
|
|
|
||||
|
Over Temperature
|
Auto Shutdown at 120 ℃
|
|
|
|
||||
|
Short Circuit
|
Auto Shutdown
|
|
|
|
||||
|
Overload
|
Auto Shutdown
|
|
|
|
||||
|
Over / Under Voltage
|
Auto Shutdown
|
|
|
|
||||
