In order to avoid flying everywhere when crushing materials.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
newest
-
Dimension(L*W*H):
-
826*530*1120mm
-
Weight:
-
100 KG
-
Core Components:
-
Others
-
Keyword:
-
Strong Plastic Crusher
-
Raw material:
-
Plastic Products Paper Wood Metal Product
-
Blades material:
-
High Speed Steel
-
Mesh size:
-
6mm(Standard
-
Lifetime:
-
5~10 Years
-
CRUSH CHAMBER:
-
190x138mm
-
Speed(r/min):
-
720
-
Material:
-
Stainless Steel
-
Power Supply:
-
Electricity
Quick Details
-
Application:
-
Grinding, Recycle Waste Plastic
-
Capacity(t/h):
-
80-150
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
newest
-
Dimension(L*W*H):
-
826*530*1120mm
-
Weight:
-
100 KG
-
Core Components:
-
Others
-
Keyword:
-
Strong Plastic Crusher
-
Raw material:
-
Plastic Products Paper Wood Metal Product
-
Blades material:
-
High Speed Steel
-
Mesh size:
-
6mm(Standard
-
Lifetime:
-
5~10 Years
-
CRUSH CHAMBER:
-
190x138mm
-
Speed(r/min):
-
720
-
Material:
-
Stainless Steel
-
Power Supply:
-
Electricity
Product Description
Stainless steel crushing machines are suitable for crushing traditional Chinese medicine herbs,chemical materials,ore with low rigidity,polystyrene,polypropylene,nylon,industrial plastic,abandoned or defected objects of polychlorinated foam soft plastic,injection sprays.The matching sieve hole board can be replaced and distance between knives blades can be adjusted.Meanwhile,the machine can crush kinds of abandoned plastic products such as blowing moulding films,film extension,thin tablets,thin boards,bottles of mineral water etc
|
Model
|
NT-180S
|
NT-250S
|
NT-400S
|
NT-600S
|
NT-800S
|
||||
|
Voltage (V)
|
220
|
380
|
380
|
380
|
380
|
||||
|
Power supply(KW)
|
2.2
|
4
|
7.5
|
15
|
22
|
||||
|
Motive knives(pcs)
|
9
|
6
|
12
|
18
|
24
|
||||
|
Fixed knives(pcs)
|
2
|
2
|
2
|
4
|
4
|
||||
|
Crushing capability(kg/h)
|
80-150
|
120-280
|
200-400
|
300-500
|
500-1000
|
||||
|
Aperture of sieve mesh (mm)
|
Standard aperture is 6mm/8mm, 10-30mm can be customized.
|
|
|
|
|
||||
|
Velocity of spindle ratation(r/min)
|
720
|
690
|
600
|
490
|
450
|
||||
|
Feeding caliber(mm)
|
190*138
|
245*165
|
405*208
|
605*213
|
805*228
|
||||
|
Dimension(mm)
|
826*530*1123
|
1002*625*1158
|
1178*805*1300
|
1187*1046*1502
|
1575*1245*1582
|
||||
Detailed Images
Feeding inlet adops window curtain design
-
-
-
Powerful motor
-
Asynchronous motor of dual value capacity
The overheat protection device installed in the motor protects the system together with power interlock.
Engraving prints on the bolts are a slippery-proof design.
Screw it up easily
Forbidden happening in danger
the sdge of the machine adopts round&smooth design to avoid cutting hands
Replacement sll in one stop
Installing appropriate sieve mesh according to the particle size of crushed objects.
Exported advanced stainless steel
The knives are flexible and adjustable.
The blunt knives can be sharpened for many times.
Long life for knife use
Application
The machine can crush kinds of abandoned plastic products such as blowing moulding films,film extension,thin tablets,thin boards,bottles of mineral water etc
Related Products
FAQ
Q1: What are the payment terms?
A: We usually accept payment by T/T, L/C, Western Union or Escrow.
Q2 size any of the products be custom imprinted?
A: The mold is available to be customized.
Q3: This is my first time to import, how can I trust your company and ensure to get the goods if I order from you?
A: We are alibaba legitimate certification company, and we support payment terms like L/C, Escrow,Trade Insurance to ensure your safety.
Q4: How to ensure that I received the machine undamaged?
A: At first , our package is standard for shipping and before packing, we will confirm product undamaged, otherwise, please contact within 2days.
Because we've bought insurance for you, we or shipping company will be responsible!
Because we've bought insurance for you, we or shipping company will be responsible!
Q5 : Where will the orders be shipped from?
A: It will ship from the main ports China,Shanghai ,Qingdao,Tianjin.
