Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
YXFB
-
Model Number:
-
CH0801B
-
IP level:
-
66
-
Product name:
-
Explosion Proof Waterproof Start Stop Push Button Switch
-
Color:
-
According to your requirement
-
Material:
-
Plastic
-
Certification:
-
Ex NEPSI & CNEX
-
Working temperature:
-
-55 ~ +60
-
Rated voltage:
-
DC220, AC415/240,
-
Mechanical life:
-
1 million times
-
Corrosion protection grade:
-
WF2
-
Intended use:
-
zone 1&2 or zone 21,22
-
Contact type:
-
1NC/1NO, 2NC,2NO, and others
Quick Details
-
Protection Level:
-
IP66
-
Max. Current:
-
16A
-
Max. Voltage:
-
250V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
YXFB
-
Model Number:
-
CH0801B
-
IP level:
-
66
-
Product name:
-
Explosion Proof Waterproof Start Stop Push Button Switch
-
Color:
-
According to your requirement
-
Material:
-
Plastic
-
Certification:
-
Ex NEPSI & CNEX
-
Working temperature:
-
-55 ~ +60
-
Rated voltage:
-
DC220, AC415/240,
-
Mechanical life:
-
1 million times
-
Corrosion protection grade:
-
WF2
-
Intended use:
-
zone 1&2 or zone 21,22
-
Contact type:
-
1NC/1NO, 2NC,2NO, and others
Product Description
Description
*Explosion-proof component composed of explosion-proof module + operating head. The standard diameter of the front operating head ofthe componen is ∅30mm,which is installed on a 1~6mm thick panel.
*The front railtype explosion-proof componentis instaed on a 35mm standard railor fixed with screws; the reartype module is connected to the preinstaled front operating head by means of a bayonet clamp.
*The front rail lype and rear ype explosion-proof components are atached with wiring terminals. The front ral lype and rear lype explosion-proof componentsshould be installed in an increased safety enclosure with a protection level ofiP54 or higher.
*A variely of button operation heads and switch operalion heads with diferentfunclions can be seleced for the front railtype and rearlype explosion-proor buttons and switches.
*The front guide rail lype and the rear type explosion-proof signal lamp element adopts LED lightsource, and there is a temperaure switch inside. There arefive colors to choose from.
*The panel of the front guide rai lype and the back type explosion-proof ammeter is equipped with a red adjiustable pointer,which is equipped with two-foldand five-fold overload functions, which can be divided into direct and indirect measurement.
*Direct measuremen is suitable for the curentrange of 0-10A;the ammeter dial ofindirect measurement (connected to curent ransformer) is interchangeable
*The sign of the button can be permanently retained after sintering.
*The rated current ofthe explosion-proofswitch module can reach 16A, and the mechanicallife can reach 1 milion times.The contact materials are dividedinto silver dots and silver dots gold-plated.
*Explosion-proofsianallamp componens have the characlerisics ofhich briohtness and ona life, and the electicalife can reach more than 100. 000 hours.
*Explosion-proofmark:Ex de ll C Gb/Ex tD A21 IP66 T80℃
Specification
|
item
|
value
|
|
Whether the smart
|
NO
|
|
Place of Origin
|
China
|
|
|
Zhejiang
|
|
Brand Name
|
YXFB
|
|
Model Number
|
CH0801-P3
|
|
Protection Level
|
IP66
|
|
Max. Current
|
16A
|
|
Max. Voltage
|
250V
|
|
LED
|
NO
|
|
Product name
|
Explosion Proof Waterproof Start Stop Push Button Switch
|
|
Color
|
According to your requirement
|
|
Material
|
Plastic
|
|
Certification
|
Ex NEPSI & CNEX
|
|
Working temperature
|
-55 ~ +60
|
|
Rated voltage
|
DC220, AC415/240,
|
|
Mechanical life
|
1 million times
|
|
Corrosion protection grade
|
WF2
|
|
Intended use
|
zone 1&2 or zone 21,22
|
|
Contact type
|
1NC/1NO, 2NC,2NO, and others
|
